System And Components
1W-7120 LINES GP-AIRS/N 6NC1-UP; R6J1-UP; 08Z1-UP
Group No: 1W-7120
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T6764 | 1 PLUG-PIPE (1/8-27-THD) | 1 | |
| 1W7813 | 2 PIPE-HEAD INLET | 1 | |
| 0S1591 | 3 BOLT (3/8-16X1.5-IN) | 5 | |
| 7S4097 | 4 ADAPTER-EXHAUST MANIFOLD | 1 | |
| 4L8337 | 5 SEAL-O-RING | 4 | |
| 0L1351 | 6 BOLT (3/8-16X0.875-IN) | 1 | |
| 7W1944 | 7 RETAINER | 1 | |
| 1W7814 | 8 ELBOW | 1 | |
| 3J7352 | 9 CONNECTOR | 1 | |
| 2B2404 | 10 CLIP | 2 | |
| 2W0160 | 11 TUBE AS-CONTROL | 1 | |
| 9S8752 | 12 NUT-FULL (3/8-16-THD) | 4 | |
| 1S4295 | 13 GASKET (TURBOCHARGER) | 1 | |
| 0S1571 | 14 BOLT (3/8-16X1.75-IN) | 4 | |
| 7F3425 | 15 BOLT (3/8-16X5.75-IN) | 1 | |
| 2N1287 | 16 ELBOW-FLARED | 1 | |
| 9S7083 | 17 GASKET-INLET | 1 | |
| 3J7354 | 18 SEAL-O-RING | 1 | |
| 1B5170 | 19 PLUG-PIPE | 1 | |
| 2H3755 | 20 BOLT (5/16-18X0.43-IN) | 2 | |
| 9M1974 | 21 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 5B3850 | 22 WASHER (9.9X15.9X2-MM THK) | 1 |
