System And Components
100-8936 AFTERCOOLER GP-WATERS/N 6NC1-UP; R6J1-UP; 08Z1-UP
Group No: 100-8936
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1261689 | 1 COVER AS | 1 | |
| 1H6525 | INSERT | 4 | |
| 1H5514 | 2 BOLT (5/16-18X1.625-IN) | 22 | |
| 9M1974 | 3 WASHER-HARD (8.8X16X2-MM THK) | 24 | |
| 9L5908 | 4 GASKET | 2 | |
| 7W0491 | 5 CORE AS-AFTERCOOLER | 1 | |
| 5S6735 | 6 GASKET | 2 | |
| 8T6762 | 7 PLUG-PIPE (1/2-14-THD) | 1 | |
| 0310219 | 8 BOLT-LOCKING (3/8-16X1.75-IN) | 3 | |
| 5M2894 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 1261688 | 10 HOUSING | 1 | |
| 9L5903 | 11 ADAPTER | 2 | |
| 6L1648 | 12 SEAL-O-RING | 2 | |
| 2W3679 | 13 GASKET | 2 | |
| 9L2625 | 14 FLANGE-TRANSFER PIPE | 1 | |
| 1N9372 | 15 GASKET-FLANGE (AIR INLET) | 1 | |
| 0343557 | 16 BOLT-LOCKING (3/8-16X1.125-IN) | 4 | |
| 3979301 | 17 WASHER-HARD (11.5X20X15-MM THK) | 3 | |
| 8T6765 | 18 PLUG-PIPE (1/4-18-THD) | 1 | |
| 2B2694 | 19 BOLT (5/16-18X2-IN) | 2 | |
| 4Y7509 | 20 BRACKET AS | 1 | |
| 0L2070 | 21 BOLT (3/8-16X2.25-IN) | 3 |
