System And Components
8N-6796 CYLINDER HEAD GPS/N 6NC1-UP; R6J1-UP; 08Z1-UP; 10Z1-UP; 13Z1-UP
Group No: 8N-6796
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1487425 | 1 GUIDE-VALVE (STANDARD) | 12 | |
| 1546997 | GUIDE-VALVE (0.51-MM OS) | ||
| 1546998 | GUIDE-VALVE (0.13-MM OS) | ||
| 5M2894 | 2 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8T6762 | 3 PLUG-PIPE (1/2-14-THD) | 3 | |
| 5S6735 | 4 GASKET | 1 | |
| 1P6367 | 5 COVER | 1 | |
| 0S1594 | 6 BOLT (3/8-16X1-IN) | 4 | |
| 8T6763 | 7 PLUG-PIPE (1/4-18-THD) | 1 | |
| 8N4485 | 8 VALVE AS-VENT (ENGINE COOLANT) | 1 | |
| 1070265 | 9 INSERT-VALVE SEAT (EXHAUST)(STANDARD) | 6 | |
| 1118025 | INSERT-VALVE SEAT (0.13-MM OS, EXHAUST) | ||
| 1118026 | INSERT-VALVE SEAT (0.25-MM OS, EXHAUST) | ||
| 1118027 | INSERT-VALVE SEAT (0.51-MM OS, EXHAUST) | ||
| 1118028 | INSERT-VALVE SEAT (0.76-MM OS, EXHAUST) | ||
| 1070268 | 10 INSERT-VALVE SEAT (INLET)(STANDARD) | 6 | |
| 1118021 | INSERT-VALVE SEAT (0.13-MM OS, INLET) | ||
| 1118022 | INSERT-VALVE SEAT (0.25-MM OS, INLET) | ||
| 1118023 | INSERT-VALVE SEAT (0.51-MM OS, INLET) | ||
| 1118024 | INSERT-VALVE SEAT (0.76-MM OS, INLET) | ||
| 3B0623 | 11 PLUG-CUP (25.73-MM OD) | 6 | |
| 3S8313 | 12 PLUG-CUP | 7 | |
| 3P1896 | 13 PLUG-CUP (35.31-MM OD) | 13 |
