122-5954 CYLINDER BLOCK GPS/N 8WM1-2261

Group No: 122-5954

Part Number	Part Name	Qty
1011173	1 CYLINDER BLOCK AS	1
9M1974	2 WASHER-HARD (8.8X16X2-MM THK)	16
1A2029	4 BOLT (3/8-16X1.125-IN)	2
7X7731	5 PLUG-PIPE (3/4-14-THD)	2
9S4191	6 PLUG (9/16-18-THD)	6
2W2940	7 PLUG (OIL MANIFOLD)	8
7N2044	8 DOWEL	2
8T6762	9 PLUG-PIPE (1/2-14-THD)	4
5M2894	10 WASHER-HARD (10.2X18.5X2.5-MM THK)	18
7N2047	11 DOWEL	3
7X4805	12 SEAL-O-RING	3
1623898	13 TUBE AS (FOR USE WITH 2-PC PISTON ONLY)	16
0T0102	14 BOLT (3/8-16X0.625-IN)	16
1011198	15 BEARING-CAMSHAFT	18
4N0683	16 DOWEL	2
8T6763	17 PLUG-PIPE (1/4-18-THD)	26
8T0099	19 DOWEL	32
7N5641	20 PLUG-MANIFOLD	2
1977008	21 DOWEL	16
5P0840	22 SEAL-O-RING	32
1445692	23 GASKET-PLATE	16
1106994	24 PLATE-SPACER	16
5F9657	25 SEAL-O-RING	4
5P8210	26 SEAL-O-RING	2
0S1595	27 BOLT (1/2-13X1.25-IN)	2
5P8245	28 WASHER-HARD (13.5X25.5X3-MM THK)	2
8N8056	29 COVER	2
6V3348	30 SEAL-O-RING	8
1213558	31 RETAINER AS (FOR USE WITH 2-PC PISTON ONLY)(PISTON COOLING JET)	16
6V3537	DOWEL	1
1B2790	32 BOLT (5/16-18X1.375-IN)	16
1534906	34 SEAL-O-RING	6
