System And Components
153-7479 LINES GP-TURBOCHARGER OILS/N 8WM1-UP
Group No: 153-7479
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W0752 | 1 GASKET | 4 | |
| 4P0692 | 2 CLAMP AS | 24 | |
| 1081434 | GROMMET | 1 | |
| 4P4460 | 3 GASKET | 4 | |
| 6I0804 | 4 ADAPTER-TURBOCHARGER OIL (SUPPLY, RH) | 3 | |
| 6I0805 | 5 ADAPTER-TURBOCHARGER OIL (SUPPLY, LH) | 1 | |
| 6I0812 | 6 TUBE AS-OIL | 1 | |
| 6K5535 | 7 CLIP (SLOT) | 4 | |
| 6K5536 | 8 CLIP (TAB) | 4 | |
| 7E0949 | 9 TUBE AS | 1 | |
| 7E5330 | 10 BRACKET | 12 | |
| 7E5335 | 11 BRACKET | 4 | |
| 7N5094 | 12 ELBOW-DRAIN | 4 | |
| 7N7559 | 13 GASKET | 4 | |
| 9Y5814 | 14 ELBOW-DRAIN | 4 | |
| 0038581 | 15 TEE-UNION | 2 | |
| 3574615 | 16 ELBOW AS | 1 | |
| 1412375 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 1843229 | 17 HOSE AS | 2 | |
| 1843230 | 18 HOSE AS | 2 | |
| 1874603 | 19 TUBE AS | 1 | |
| 1874604 | 20 TUBE AS | 1 | |
| 4504986 | 21 TUBE AS-OIL (LH) | 2 | |
| 4504985 | 22 TUBE AS-OIL (RH) | 2 | |
| 2501498 | 23 ELBOW AS | 1 | |
| 6V4589 | SEAL-O-RING | 1 | |
| 2501497 | ELBOW | 1 | |
| 0L1143 | 24 BOLT (3/8-16X2.5-IN) | 12 | |
| 0S1588 | 25 BOLT (3/8-16X1.25-IN) | 16 | |
| 0S1594 | 26 BOLT (3/8-16X1-IN) | 4 | |
| 0S1608 | 27 BOLT (3/8-16X3.75-IN) | 4 | |
| 0S1617 | 28 BOLT (5/16-18X0.75-IN) | 12 | |
| 0T0055 | 29 BOLT (3/8-16X4.25-IN) | 8 | |
| 3650578 | 30 CONNECTOR AS | 3 | |
| 2P7636 | CONNECTOR (3/4-16 STR-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3B1915 | 31 BOLT (3/8-16X1.375-IN) | 4 | |
| 3E4352 | 32 WASHER-HARD (8.8X20.5X2.5-MM THK) | 12 | |
| 5M2894 | 33 WASHER-HARD (10.2X18.5X2.5-MM THK) | 20 | |
| 2501496 | 34 ELBOW | 2 | |
| 1123540 | 35 SEAL-O-RING | 8 | |
| 9L9132 | 38 WASHER-HARD (10.2X25.5X2.5-MM THK) | 8 | |
| 3650576 | 39 CONNECTOR AS | 1 | |
| 9M4584 | CONNECTOR | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 9S8752 | 40 NUT-FULL (3/8-16-THD) | 16 | |
| 9X6458 | 41 WASHER-HARD (10.2X22.5X3-MM THK) | 12 |
