System And Components
177-9068 LINES GP-AIR -AFTERCOOLERS/N 8WM1-693
Group No: 177-9068
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V1943 | 1 BOLT-HIGH TEMPERATURE (3/8-16X1.125-IN) | 8 | |
| 7C2023 | 2 ELBOW-EXHAUST | 2 | |
| 7C7909 | 3 ELBOW (AIR INLET) | 14 | |
| 7C7910 | 4 ELBOW (AIR INLET) | 2 | |
| 7C8199 | 5 FLANGE | 16 | |
| 7N5080 | 6 GASKET-MANIFOLD | 16 | |
| 7W1944 | 7 RETAINER | 2 | |
| 7W3145 | 8 PLATE | 6 | |
| 2839779 | 9 MANIFOLD (INLET AIR) | 1 | |
| 1123591 | 10 COVER | 2 | |
| 1213562 | 11 PIPE | 1 | |
| 1236914 | 12 BAR | 2 | |
| 1236915 | 13 PLATE | 1 | |
| 1467383 | 14 FLANGE | 4 | |
| 1550540 | 15 ELBOW | 1 | |
| 1550541 | 16 ELBOW | 1 | |
| 1550544 | 17 ELBOW | 2 | |
| 1550545 | 18 ELBOW | 2 | |
| 1566261 | 19 BRACKET | 4 | |
| 1569830 | 20 ELBOW | 1 | |
| 1569831 | 21 ELBOW | 1 | |
| 1609843 | 22 ADAPTER | 2 | |
| 0S0509 | 23 BOLT (3/8-16X0.75-IN) | 6 | |
| 0S1590 | 24 BOLT (3/8-16X2-IN) | 8 | |
| 1653929 | 25 BOLT (3/8-16X1.5-IN) | 32 | |
| 0S1594 | 26 BOLT (3/8-16X1-IN) | 8 | |
| 0S1619 | 27 BOLT (3/8-16X3-IN) | 4 | |
| 0T0573 | 28 BOLT (3/8-16X2.75-IN) | 4 | |
| 1097411 | 29 SEAL-O-RING | 4 | |
| 1A1460 | 30 BOLT (1/2-13X2-IN) | 4 | |
| 1A2029 | 31 BOLT (3/8-16X1.125-IN) | 14 | |
| 1T0720 | 32 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 64 | |
| 2A4639 | 33 BOLT (3/8-16X1.625-IN) | 32 | |
| 3J5389 | 34 PLUG (EXTERNAL) | 2 | |
| 4S5898 | 35 SEAL-O-RING | 16 | |
| 5D5957 | 36 SEAL-O-RING | 4 | |
| 5M2894 | 37 WASHER-HARD (10.2X18.5X2.5-MM THK) | 168 | |
| 5P8245 | 38 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5P8940 | 39 SEAL-O-RING | 3 | |
| 6V3917 | 40 SEAL-O-RING | 16 | |
| 6V5101 | 41 SEAL-O-RING | 16 | |
| 8T6762 | 42 PLUG-PIPE (1/2-14-THD) | 7 | |
| 8T6764 | 43 PLUG-PIPE (1/8-27-THD) | 4 | |
| 9F2773 | 44 BOLT (3/8-16X8.5-IN) | 12 | |
| 9X6458 | 45 WASHER-HARD (10.2X22.5X3-MM THK) | 8 |
