System And Components
144-0744 AIR COMPRESSOR GPS/N 6NC1-UP; R6J1-UP; 08Z1-UP; 13Z1-UP
Group No: 144-0744
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N7448 | 1 GASKET | 1 | |
| 7N7447 | 2 HEAD AS-COMPRESSOR | 1 | |
| 0S1619 | 3 BOLT (3/8-16X3-IN) | 5 | |
| 4W9479 | 4 MANIFOLD-EXHAUST | 1 | |
| 1S7107 | GASKET | 1 | |
| 0L1352 | 5 BOLT (3/8-16X3.25-IN) | 1 | |
| 2B2695 | 6 BOLT (5/16-18X0.875-IN) | 2 | |
| 9M1974 | 7 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 7N7450 | 8 COVER-UNLOADER | 1 | |
| 7N7451 | GASKET-UNLOADER | 1 | |
| 0S1615 | 9 BOLT (1/4-20X0.75-IN) | 2 | |
| 5P0537 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8T6762 | 10 PLUG-PIPE (1/2-14-THD) | 2 | |
| 7N7441 | 11 COVER-AIR COMPRESSOR | 1 | |
| 7N7442 | GASKET | 1 | |
| 8T6757 | 12 PLUG-PIPE | 1 | |
| 0344160 | 13 BOLT-LOCKING (5/16-18X1-IN) | 4 | |
| 5M2894 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 0S1617 | 15 BOLT (5/16-18X0.75-IN) | 6 | |
| 7N7439 | 16 PLATE-COVER | 1 | |
| 7N7440 | GASKET | 1 | |
| 8H9789 | 17 BALL BEARING | 2 | |
| 4P2974 | 18 CRANKSHAFT AS | 1 | |
| 1W7147 | 19 CRANKCASE-COMPRESSOR | 1 | |
| 1A2029 | 20 BOLT (3/8-16X1.125-IN) | 6 | |
| 7X7732 | 21 PLUG-PIPE | 1 | |
| 7N7445 | 22 CYLINDER BLOCK | 1 | |
| 7N7446 | GASKET | 1 | |
| 4W9489 | 23 RING-LOCK | 1 | |
| 1389057 | 24 VALVE (PRESSURE RELIEF) | 1 | |
| 7N7435 | KIT-AIR COMPRESSOR (MAJOR REPAIR) | 1 | |
| 1440502 | KIT-PISTON RING (STANDARD) | 1 | |
| 1440503 | KIT-PISTON & RING (STANDARD) | 1 | |
| 1382887 | KIT-ROD & BEARING | 1 |
