System And Components
8N-0246 CYLINDER HEAD GPS/N 6NC1-UP; R6J1-UP; 08Z1-UP; 10Z1-UP; 13Z1-UP
Group No: 8N-0246
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T6762 | 1 PLUG-PIPE (1/2-14-THD) | 1 | |
| 1487425 | 2 GUIDE-VALVE | 12 | |
| 3J5389 | 3 PLUG (EXTERNAL) | 2 | |
| 1118015 | 4 GASKET AS-CYLINDER HEAD | 1 | |
| 8T6763 | 5 PLUG-PIPE (1/4-18-THD) | 1 | |
| 1W5300 | 6 ROTOCOIL AS | 12 | |
| 1487455 | 7 VALVE-EXHAUST | 6 | |
| 2A4429 | 8 LOCK-RETAINER | 24 | |
| 7S7144 | 9 SPRING-VALVE | 12 | |
| 1007860 | 10 VALVE-INLET | 6 | |
| 3S5496 | 11 SEAL-O-RING | 1 | |
| 9Y1798 | 12 SEAL | 18 | |
| 7N8018 | 13 SEAL | 6 | |
| 7C4006 | 14 CYLINDER HEAD AS | 1 | |
| 1070268 | 15 INSERT-VALVE SEAT (INLET) | 6 | |
| 1070265 | 16 INSERT-VALVE SEAT (EXHAUST) | 6 | |
| 3B0623 | PLUG-CUP (25.73-MM OD) | 6 | |
| 3P1896 | PLUG-CUP (35.31-MM OD) | 13 | |
| 3S8313 | PLUG-CUP | 7 |
