System And Components
349-8575 HOUSING GP-FRONTS/N 9YJ1078-UP
Group No: 349-8575
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1331011 | 1 WASHER | 1 | |
| 0676179 | 2 DOWEL | 1 | |
| 3199361 | 3 GASKET | 1 | |
| 3254374 | 4 PLATE-THRUST | 1 | |
| 3718057 | 5 COVER-FRONT | 1 | |
| 3718062 | 6 SEAL | 1 | |
| 3355330 | 7 GASKET | 1 | |
| 3400571 | 8 GEAR (72-TEETH) | 1 | |
| 3421306 | 9 IDLER AS (97-TEETH) | 1 | |
| 4190423 | 10 HUB-IDLER GEAR | 1 | |
| 5023519 | 11 CASE-GEAR | 1 | |
| 2323666 | 12 WASHER-THRUST | 1 | |
| 1003751 | 13 BOLT (M8X1.25X65-MM) | 6 | |
| 1013895 | 14 BOLT (M8X1.25X35-MM) | 2 | |
| 6I0217 | 15 BOLT (M8X1.25X20-MM) | 17 | |
| 6I0645 | 16 BOLT (M8X1.25X25-MM) | 3 | |
| 6I0789 | 17 BOLT (M10X1.5X60-MM) | 3 | |
| 7C4616 | 18 BOLT (M12X1.75X45-MM) | 1 |
