System And Components
509-7096 MANIFOLD GP-EXHAUSTS/N 9YJ1078-UP
Group No: 509-7096
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1068916 | 1 BOLT (M6X1X16-MM) | 2 | |
| 1243815 | 2 BOLT (M8X1.25X16-MM) | 4 | |
| 1978418 | 3 GASKET | 1 | |
| 1978419 | 4 GASKET | 1 | |
| 2388292 | 5 BOLT-FLANGE HEAD | 12 | |
| 2416170 | 6 PLUG (M14X1.5-THD) | 1 | |
| 2780017 | 7 GASKET | 2 | |
| 2867851 | 8 SPACER | 12 | |
| 3499387 | 9 MANIFOLD | 1 | |
| 3570617 | 10 GASKET | 1 | |
| 3717601 | 11 GASKET | 2 | |
| 4322374 | 12 LINE AS | 1 | |
| 4322376 | 13 LINE AS | 1 | |
| 4508002 | 14 LINE AS | 1 | |
| 3P0647 | 14A SEAL-O-RING | 2 | |
| 9N1756 | 14B SEAL-O-RING | 1 | |
| 4508003 | 15 LINES GP-TURBOCHARGER OIL | 1 | |
| 3P0647 | 15A SEAL-O-RING | 2 | |
| 4508004 | 16 ADAPTER AS | 1 | |
| 0335879 | 16A SEAL-O-RING | 1 | |
| 4510548 | 17 BOLT | 2 | |
| 6I0217 | 18 BOLT (M8X1.25X20-MM) | 4 | |
| 6I0254 | 19 BOLT (M8X1.25X30-MM) | 2 | |
| 2287101 | 20 SEAL-O-RING | 1 |
