System And Components
447-7073 LINES GP-FUELS/N KB41-UP
Group No: 447-7073
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1925017 | 1 BRACKET AS | 1 | |
| 3105899 | 4 ADAPTER-ELBOW | 1 | |
| 3510265 | 5 VALVE-BALL | 1 | |
| 3550632 | 6 CONNECTOR-SPECIAL | 2 | |
| 3550633 | 7 COUPLER-QUICK DISCONNECT | 1 | |
| 3830750 | 8 HOSE AS | 1 | |
| 3893691 | 9 CONNECTOR AS | 1 | |
| 8T1715 | ADAPTER | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 4189430 | 10 HOSE AS | 1 | |
| 4426294 | 11 SHIM (5-MM THK) | 1 | |
| 4482643 | 12 HOSE AS | 1 | |
| 4482650 | 13 HOSE AS | 1 | |
| 0919035 | 14 SPACER (11X25X20-MM THK) | 5 | |
| 1S0994 | 15 CLIP (LOOP) | 2 | |
| 2287089 | 16 SEAL-O-RING | 1 | |
| 2287090 | 17 SEAL-O-RING | 2 | |
| 2287102 | 18 SEAL-O-RING | 2 | |
| 2385080 | 19 SEAL-O-RING | 2 | |
| 2385081 | 20 SEAL-O-RING | 1 | |
| 2458842 | 21 CLIP (LOOP) | 5 | |
| 3196233 | 22 TEE AS | 1 | |
| 6V8782 | TEE | 1 | |
| 2287090 | SEAL-O-RING | 2 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3309772 | 23 ELBOW AS | 1 | |
| 6V8624 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3453923 | 24 ADAPTER-HOSE | 1 | |
| 4D7388 | 25 CLIP | 1 | |
| 5P4325 | 26 CLIP (LOOP) | 1 | |
| 5P4961 | 27 CLAMP-HOSE | 7 | |
| 7S3916 | 29 CLIP (TAB) | 1 | |
| 7S3919 | 30 CLIP (SLOT) | 1 | |
| 7V6571 | 31 GROMMET | 1 | |
| 8M2773 | 32 CLIP (LOOP) | 2 | |
| 8T4121 | 33 WASHER-HARD (11X21X2.5-MM THK) | 13 | |
| 8T4137 | 34 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4182 | 35 BOLT (M10X1.5X45-MM) | 2 | |
| 8T4186 | 36 BOLT (M10X1.5X40-MM) | 3 | |
| 8T4195 | 37 BOLT (M10X1.5X30-MM) | 3 | |
| 8T4224 | 38 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T6912 | 39 BOLT (M8X1.25X50-MM) | 3 | |
| 8T7488 | 40 CONNECTOR | 2 | |
| 9M8406 | 41 CLIP (LOOP) | 1 | |
| 3478646 | 42 HOSE (42-CM) | ||
| 3478645 | 43 HOSE (62-CM) | ||
| 3478645 | 43A HOSE (30-CM) | ||
| 8T4136 | 45 BOLT (M10X1.5X25-MM) | 1 |
