450-1522 PANEL GP-CIRCUIT BREAKERS/N KB4425-UP

Group No: 450-1522

Part Number	Part Name	Qty
3830772	1 PLATE AS	1
7K1181	2 STRAP-CABLE	3
1712212	3 CIRCUIT BREAKER AS (105-AMPERE)(MAIN)	1
2164970	4 CIRCUIT BREAKER AS (120-AMPERE)(ALTERNATOR)	1
1H3244	LOCKWASHER	2
4E5724	WASHER (7X12X1-MM THK)	2
8T0122	NUT-FULL (1/4-28-THD)	2
2313930	5 RELAY AS (24-VOLT)(BLOWER FAN SPEED)	1
2418368	6 SWITCH GP-MAGNETIC (24-VOLT)(GLOW PLUG RELAY)	1
2431353	7 SPACER (11X20X35-MM THK)	1
3687944	8 COVER	1
3811040	9 STRIP	1
3849919	10 STRIP	1
4456694	11 CABLE AS	1
8C0596	CABLE (2-GA)(66-CM)
0301712	TERMINAL-RING (2-GA, 1/4-IN SCREW)	1
3116184	TERMINAL-RING (2-GA, 3/8-IN SCREW)	1
4652370	12 HARNESS AS-PANEL	1
4652371	13 CABLE AS	1
8C3056	CABLE (2-GA, RED)(154-CM)
1257876	TUBE-HEAT SHRINK (17.78-MM DIA)(7-CM)
1352543	BOOT (RED)	1
1P0810	TAPE-ELECTRICAL
2781438	TERMINAL-RING	1
4652372	14 CABLE AS	1
6T5598	TERMINAL-RING (1-GA TO 2-GA, 5/16-IN SCREW)	1
8C3056	CABLE (2-GA, RED)(188-CM)
1352543	BOOT (RED)	2
1566451	15 SCREW-PAN HEAD (8-32X1-IN)	6
1684511	16 SCREW-PAN HEAD (10-32X1-IN)	4
1S0496	17 CLIP	1
2640168	18 STUD-TAPERLOCK (M10X1.5X50-MM)	2
3445675	19 NUT (M10X1.5-THD)	2
3537957	20 GROMMET	9
4B2043	21 NUT (8-32-THD)	2
5C2890	22 NUT (M6X1-THD)	3
5H6565	23 CIRCUIT BREAKER AS (30-AMPERE)(ENGINE ECM)	1
6V8376	SCREW-MACHINE (8-32X0.25-IN)	2
9B7233	LOCKWASHER	2
6D4246	24 CLIP (LOOP)	8
6V7357	25 BOLT (M6X1X25-MM)	7
8D7265	26 CIRCUIT BREAKER AS (40-AMPERE)(GLOW PLUG)	1
6V8376	SCREW-MACHINE (8-32X0.25-IN)	2
9B7233	LOCKWASHER	2
8T4121	27 WASHER-HARD (11X21X2.5-MM THK)	4
8T4137	28 BOLT (M10X1.5X20-MM)	1
8T4183	29 BOLT (M12X1.75X40-MM)	2
8T4223	30 WASHER-HARD (13.5X25.5X3-MM THK)	2
8T6466	31 BOLT (M10X1.5X60-MM)	1
9G9882	32 CIRCUIT BREAKER AS (10-AMPERE)(HYDRAULIC FILL PUMP)	1
6V8376	SCREW-MACHINE (8-32X0.25-IN)	2
9B7233	LOCKWASHER	2
9X8256	33 WASHER (6.6X12X2-MM THK)	10
