System And Components
351-8193 SENSOR GP-ENGINES/N C8N1-UP
Group No: 351-8193
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1999252 | 1 SEAL-O-RING | 3 | |
| 1999267 | 2 SEAL-O-RING | 4 | |
| 1999751 | 3 SEAL-O-RING | 1 | |
| 2566454 | 4 SENSOR-TEMPERATURE (2-PIN)(COOLANT TEMPERATURE) | 1 | |
| 2566454 | 4A SENSOR-TEMPERATURE (2-PIN)(AIR INLET MANIFOLD) | 1 | |
| 2765603 | 5 SEAL-O-RING | 1 | |
| 3203060 | 6 SENSOR GP-PRESSURE (ENGINE OIL PRESSURE) | 1 | |
| 3203061 | 7 SENSOR GP-PRESSURE (NRS OUTLET) | 1 | |
| 3203061 | 7A SENSOR GP-PRESSURE (NRS INLET) | 1 | |
| 3203062 | 8 SENSOR GP-PRESSURE (INTAKE MANIFOLD AIR) | 1 | |
| 3203063 | 9 SENSOR GP-PRESSURE (ATMOSPHERIC) | 1 | |
| 3327865 | 10 TIE-CABLE | 2 | |
| 3398822 | 11 SENSOR AS-TEMPERATURE (NOX REDUCTION SYSTEM) | 1 | |
| 2818802 | 11A RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 3887603 | 12 MANIFOLD AS | 1 | |
| 2956661 | 12A PLUG | 1 | |
| 3854319 | 13 PIPE AS | 1 | |
| 3308196 | 13A SEAL-O-RING | 2 | |
| 3854320 | 14 PIPE AS | 1 | |
| 3308196 | 14A SEAL-O-RING | 2 | |
| 3691202 | 15 BRACKET AS | 1 | |
| 3589934 | 16 UNION | 2 | |
| 3850697 | 17 CLAMP | 2 | |
| 1243815 | 19 BOLT (M8X1.25X16-MM) | 7 | |
| 2284947 | 20 SEAL-O-RING | 2 | |
| 2323861 | 21 PLUG (BLANKING) | 1 | |
| 3113857 | 22 SENSOR-SPEED (TIMING, CAMSHAFT) | 1 | |
| 3113857 | 22A SENSOR-SPEED (TIMING, CRANKSHAFT) | 1 | |
| 6I0254 | 23 BOLT (M8X1.25X30-MM) | 3 | |
| 3308196 | 24 SEAL-O-RING | 1 |
