System And Components
449-9858 HOOD & GUARD GPS/N KB41-UP
Group No: 449-9858
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3192305 | 1 CAM-LATCH | 2 | |
| 1224120 | 2 ROD | 3 | |
| 3053159 | 3 PAWL | 3 | |
| 3373928 | 4 SEAL | 1 | |
| 3522979 | 5 LATCH AS | 3 | |
| 5C2890 | NUT (M6X1-THD) | 4 | |
| 1H3244 | LOCKWASHER | 4 | |
| 1608499 | NUT (M12X1.5-THD) | 2 | |
| 3260612 | WASHER-TAB | 2 | |
| 4849448 | 6 DOOR AS-ACCESS | 1 | |
| 4576687 | DOOR AS-ACCESS | 1 | |
| 4849449 | 7 DOOR AS-ACCESS | 1 | |
| 4579090 | DOOR AS-ACCESS | 1 | |
| 4849447 | 8 DOOR AS-ACCESS | 1 | |
| 4576686 | DOOR AS-ACCESS | 1 | |
| 2750572 | 9 LATCH AS | 2 | |
| 4185559 | 10 MOUNT AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 4185561 | 11 PLATE | 1 | |
| 4185563 | 12 COVER | 1 | |
| 4903336 | 13 HOOD AS | 1 | |
| 4572116 | HOOD AS | 1 | |
| 4572122 | 14 PLATE AS | 1 | |
| 4572807 | 15 DOOR AS-ACCESS | 1 | |
| 4572809 | 16 DOOR AS-ACCESS | 1 | |
| 3W4521 | HINGE | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 6V7744 | 19 LOCKNUT (M10X1.5-THD) | 2 | |
| 3B4615 | 20 PIN-COTTER | 3 | |
| 5P1076 | 21 WASHER-HARD (13.5X30X4-MM THK) | 12 | |
| 6C3679 | 22 RIVET-POP | 4 | |
| 7X7729 | 23 WASHER (11X25X3-MM THK) | 26 | |
| 8T4121 | 24 WASHER-HARD (11X21X2.5-MM THK) | 17 | |
| 8T4136 | 25 BOLT (M10X1.5X25-MM) | 38 | |
| 8T4139 | 27 BOLT (M12X1.75X30-MM) | 12 | |
| 9L9182 | 31 WASHER | 4 | |
| 6V2499 | 32 SEAL (0.7-M EACH) | ||
| 6V2499 | 32A SEAL (0.8-M) | ||
| 6V5163 | 33 SEAL (1.2-M) | ||
| 1963652 | 34 SEAL (96-CM) | ||
| 5P5637 | 35 SEAL (0.08-M EACH) | ||
| 4M7470 | 36 GROMMET | 3 |
