System And Components
374-8711 PANEL GP-CIRCUIT BREAKERS/N WTP1-UP
Group No: 374-8711
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1712210 | 1 CIRCUIT BREAKER AS (80-AMPERE)(MAIN) | 1 | |
| 1712210 | 1A CIRCUIT BREAKER AS (80-AMPERE)(LOAD) | 1 | |
| 1712210 | 1B CIRCUIT BREAKER AS (80-AMPERE)(MANUAL) | 1 | |
| 4E5724 | WASHER (7X12X1-MM THK) | 2 | |
| 8T0122 | NUT-FULL (1/4-28-THD) | 2 | |
| 1H3244 | LOCKWASHER | 2 | |
| 1712215 | 2 CIRCUIT BREAKER AS (150-AMPERE)(ALTERNATOR) | 1 | |
| 4E5724 | WASHER (7X12X1-MM THK) | 2 | |
| 8T0122 | NUT-FULL (1/4-28-THD) | 2 | |
| 1H3244 | LOCKWASHER | 2 | |
| 1724863 | 3 JUNCTION BLOCK | 1 | |
| 2418368 | 4 SWITCH GP-MAGNETIC (24-VOLT)(MAIN RELAY) | 1 | |
| 3070293 | 5 BAR-BUS | 1 | |
| 3070294 | 6 BAR-BUS | 1 | |
| 3070297 | 7 CABLE AS | 1 | |
| 5P3454 | TERMINAL-RING (4-GA, 5/16-IN SCREW) | 1 | |
| 6V2366 | CABLE-ELECTRICAL (4-GA, RED)(2-DM) | ||
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(5-CM) | ||
| 3173239 | TERMINAL-RING | 1 | |
| 3286213 | 8 PLATE | 1 | |
| 3748712 | 9 PANEL AS-BOX | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 11 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 1305300 | CLIP | 1 | |
| 1951095 | STUD-WELD (M6X1X20-MM) | 2 | |
| 3748714 | 10 PLATE | 1 | |
| 3748716 | 11 FILM-IDENTIFICATION (CIRCUIT BREAKERS) | 1 | |
| 3748768 | 12 BAR-BUS | 1 | |
| 3748818 | 13 HARNESS AS-BOX (TRACTOR) | 1 | |
| 3637123 | 13A RELAY AS (24-VOLT)(TRACTOR) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 3E3389 | WEDGE-RECEPTACLE LOCK (8-PIN) | 1 | |
| 3T3043 | RECEPTACLE AS-CONNECTOR (25-PIN) | 1 | |
| 8N1522 | NUT (2-1/4-16-THD) | 1 | |
| 5P3454 | TERMINAL-RING (4-GA, 5/16-IN SCREW) | 1 | |
| 9G4343 | TERMINAL-RING (4-GA, 1/4-IN SCREW) | 1 | |
| 7G7917 | PLUG-SEAL | 12 | |
| 7G7919 | PLUG-SEAL | 3 | |
| 7R2750 | SEAL-CONNECTOR | 7 | |
| 7R2751 | PLUG-CONNECTOR (1-PIN) | 26 | |
| 8N1523 | LOCKWASHER | 1 | |
| 9X6857 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 8N1541 | SOCKET-CONNECTOR (12-GA TO 14-GA) | 4 | |
| 8N1549 | SOCKET-CONNECTOR (4-GA) | 2 | |
| 8T8737 | PLUG-SEAL | 5 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(5-CM) | ||
| 1285016 | SEAL-CABLE | 2 | |
| 1944254 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 2020313 | TERMINAL AS (18-GA) | 2 | |
| 5P5677 | WIRE (18-GA, BLACK)(0.2-M) | ||
| 1285016 | SEAL-CABLE | 1 | |
| 2020314 | TERMINAL AS (14-GA) | 7 | |
| 5P5624 | WIRE (14-GA, BLACK)(0.2-M) | ||
| 1284123 | SEAL-CABLE | 1 | |
| 2802709 | CIRCUIT BREAKER AS (15-AMPERE, MANUAL RESET) | 5 | |
| 3060282 | BLOCK AS-FUSE | 1 | |
| 3060350 | COVER | 1 | |
| 3060351 | SEAL-COVER | 1 | |
| 4254513 | RETAINER | 1 | |
| 1138373 | 14 SCREW-BUTTON HEAD (10-32X0.75-IN) | 12 | |
| 1504086 | 15 SCREW (M4X0.7X16-MM) | 2 | |
| 4B4274 | 16 WASHER (5.5X13X1.2-MM THK) | 1 | |
| 3445673 | 17 NUT (M6X1-THD) | 3 | |
| 5C7883 | 18 BOLT-SOCKET HEAD (M6X1X16-MM) | 3 | |
| 5C8312 | 19 NUT (M4X0.7-THD) | 2 | |
| 7X2548 | 20 BOLT (M12X1.75X16-MM) | 1 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 22 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4138 | 23 BOLT (M6X1X20-MM) | 5 | |
| 8T4191 | 24 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4205 | 25 WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 8T4223 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 9B7233 | 27 LOCKWASHER | 2 | |
| 4B4277 | 28 WASHER (8.8X17.5X1.6-MM THK) | 2 |
