System And Components
355-1049 CONTROL GP-INLET AIRPART OF 481-5676 ENGINE AR-CORE
Group No: 355-1049
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0839 | 1 BOLT (M8X1.25X70-MM) | 2 | |
| 4704925 | 2 PLUG | 1 | |
| 1440367 | 3 CLAMP-HOSE | 2 | |
| 3599666 | 4 BOLT-FLANGE HEAD (M8X1.25X130-MM) | 2 | |
| 3197840 | 6 GASKET (INLET ELBOW) | 1 | |
| 4234670 | 7 BRACKET | 1 | |
| 3496805 | 8 PIPE-INLET | 1 | |
| 3545632 | 9 HOSE | 1 | |
| 3551078 | 10 CONNECTION | 1 | |
| 4795920 | 11 VALVE & MOUNTING GP (NRS) | 1 | |
| 1783336 | 12 NUT-HEX FLANGE (M8X1.25-THD) | 1 | |
| 3426268 | 13 STUD (M8X1.25X80-MM) | 1 | |
| 0358063 | 14 PLUG | 1 | |
| 1013895 | 15 BOLT (M8X1.25X35-MM) | 3 | |
| 6I0917 | 16 BOLT (M6X1X25-MM) | 2 | |
| 3496803 | 18 THROTTLE AS | 1 | |
| 3674226 | 19 VALVE-SOLENOID (WASTEGATE) | 1 | |
| 6I0456 | 20 BOLT (M8X1.25X45-MM) | 4 |
