System And Components
355-1038 TURBOCHARGER GPPART OF 481-5676 ENGINE AR-CORE
Group No: 355-1038
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1015115 | 1 STUD (M10X1.5X40-MM) | 4 | |
| 1031912 | 2 STUD (M10X1.5X30-MM) | 4 | |
| 1243815 | 3 BOLT (M8X1.25X16-MM) | 3 | |
| 3179229 | 4 CLAMP-HOSE | 2 | |
| 3293723 | 5 GASKET | 1 | |
| 3426433 | 6 DUCT | 1 | |
| 3435908 | 7 CLAMP-V BAND | 2 | |
| 3435910 | 8 CLAMP-V BAND | 1 | |
| 3484636 | 9 STUD (M10X1.5X70-MM) | 4 | |
| 3508541 | 10 BRACKET | 1 | |
| 3562122 | 11 DUCT (COMPRESSOR) | 1 | |
| 3565345 | 12 HOSE | 1 | |
| 3590128 | 13 TURBOCHARGER | 1 | |
| 3601965 | 14 LINES GP-TURBOCHARGER AIR | 1 | |
| 3659909 | 15 LINES GP-TURBOCHARGER AIR | 1 | |
| 4430317 | 16 TURBOCHARGER AS | 1 | |
| 5081306 | 16A ACTUATOR AS | 1 | |
| 4402081 | NUT | 2 | |
| 4878468 | RING | 2 | |
| 6I0563 | 17 NUT (M10X1.5-THD) | 12 |
