System And Components
7N-8874 CYLINDER HEAD GPS/N H4G1-UP; 07Z1-UP
Group No: 7N-8874
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2A4429 | 1 LOCK-RETAINER | 16 | |
| 7N8018 | 2 SEAL | 4 | |
| 7S7144 | 3 SPRING-VALVE | 8 | |
| 1007860 | 4 VALVE-INLET | 4 | |
| 1487455 | 5 VALVE-EXHAUST | 4 | |
| 4P8915 | 6 GASKET-CYLINDER HEAD | 1 | |
| 3S5496 | 7 SEAL-O-RING | 1 | |
| 9Y1798 | 8 SEAL | 12 | |
| 1W5300 | 9 ROTOCOIL AS | 8 | |
| 6N7174 | SHIELD-OIL | 1 | |
| 1487425 | 11 GUIDE-VALVE (STANDARD) | 8 | |
| 1546997 | GUIDE-VALVE (0.51-MM OS) | ||
| 1546998 | GUIDE-VALVE (0.13-MM OS) | ||
| 8T6763 | 12 PLUG-PIPE (1/4-18-THD) | 1 | |
| 3B0623 | 13 PLUG-CUP | 4 | |
| 1070265 | 14 INSERT-VALVE SEAT (EXHAUST)(STANDARD) | 4 | |
| 1118025 | INSERT-VALVE SEAT (0.13-MM OS) | ||
| 1118026 | INSERT-VALVE SEAT (0.25-MM OS) | ||
| 1118027 | INSERT-VALVE SEAT (0.51-MM OS) | ||
| 1118028 | INSERT-VALVE SEAT (0.76-MM OS) | ||
| 1070268 | 15 INSERT-VALVE SEAT (INLET)(STANDARD) | 4 | |
| 1118021 | INSERT-VALVE SEAT (0.13-MM OS, INLET) | ||
| 1118022 | INSERT-VALVE SEAT (0.25-MM OS, INLET) | ||
| 1118023 | INSERT-VALVE SEAT (0.51-MM OS, INLET) | ||
| 1118024 | INSERT-VALVE SEAT (0.76-MM OS, INLET) | ||
| 3P1896 | 16 PLUG-CUP | 9 | |
| 3S8313 | 17 PLUG-CUP | 4 | |
| 8T6762 | 18 PLUG-PIPE (1/2-14-THD)(9.52 CF SQ HOLE) | 3 |
