System And Components
188-8949 LINES GP-TURBOCHARGER OILS/N H4G1-UP; 07Z1-UP
Group No: 188-8949
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0L1143 | 1 BOLT (3/8-16X2.5-IN) | 2 | |
| 5M2894 | 2 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 7W3043 | 3 TUBE AS-OIL DRAIN | 1 | |
| 9M4849 | 4 SEAL-O-RING | 1 | |
| 1P1255 | 5 GASKET-OIL DRAIN | 1 | |
| 8M4446 | 6 SEAL-O-RING | 1 | |
| 5M6213 | 7 PLUG-PIPE | 2 | |
| 0S1585 | 8 BOLT (1/2-13X1.5-IN) | 1 | |
| 5P8245 | 9 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8M4438 | 10 SEAL-O-RING | 1 | |
| 0S1619 | 11 BOLT (3/8-16X3-IN) | 2 | |
| 5P8247 | 12 WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 1D4585 | 13 BOLT (5/8-11X3.25-IN) | 1 | |
| 9Y4380 | 14 RETAINER | 1 | |
| 8M5248 | 15 SEAL-O-RING | 2 | |
| 3J5390 | 16 PLUG (3/8-18-THD) | 1 | |
| 4W9655 | 17 SUPPORT | 1 | |
| 8H9788 | 18 GASKET | 1 | |
| 1025869 | 19 TUBE AS-OIL | 1 | |
| 1B2790 | 20 BOLT (5/16-18X1.375-IN) | 1 | |
| 4B3388 | 21 BOLT (5/16-18X1.125-IN) | 1 | |
| 1025868 | 22 HOSE AS | 1 | |
| 1240174 | 23 CLIP | 1 | |
| 6K3607 | 24 CONNECTOR | 1 | |
| 2M9780 | 25 SEAL-O-RING | 1 | |
| 9S4185 | 26 PLUG (3/4-16-THD) | 1 | |
| 3K0360 | 27 SEAL-O-RING | 1 |
