System And Components
135-5492 AFTERCOOLER GP-WATERS/N H4G1-UP; 07Z1-UP
Group No: 135-5492
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1304627 | 1 COVER-AFTERCOOLER HOUSING | 1 | |
| 1H5514 | 2 BOLT (5/16-18X1.625-IN) | 12 | |
| 9M1974 | 3 WASHER-HARD (8.8X16X2-MM THK) | 16 | |
| 1313009 | 4 GASKET | 2 | |
| 1325413 | 5 CORE AS | 1 | |
| 5S6735 | 6 GASKET | 2 | |
| 8T6762 | 7 PLUG-PIPE (1/2-14-THD)(9.52 CF SQ HOLE) | 1 | |
| 0310219 | 8 BOLT-LOCKING (3/8-16X1.75-IN) | 4 | |
| 5M2894 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 4N0205 | 10 SPACER (0.42X0.75X0.6-IN THK) | 4 | |
| 4W4993 | 11 HOUSING | 1 | |
| 9L5903 | 12 ADAPTER | 2 | |
| 2W3679 | 13 GASKET | 2 | |
| 6L1648 | 14 SEAL-O-RING | 2 | |
| 0343557 | 15 BOLT-LOCKING (3/8-16X1.125-IN) | 4 | |
| 1358825 | 16 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 1358824 | BLOCK | 1 | |
| 2B2694 | 17 BOLT (5/16-18X2-IN) | 4 | |
| 1355493 | 18 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 |
