System And Components
BATTERY BOX (9W7045 N/S)--Part 2 of 2
Group No: BATTERY
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9W7547 | 1 PLATE | 1 | |
| 9W7541 | 2 COVER ASSEM. | 1 | |
| 9F2978 | 3 NUT (WELD) | 13 | |
| 6J0488 | 4 SCREW | 9 | |
| 7T7523 | 5 PLATE ASSEM. | 1 | |
| 1F0748 | NUT (WELD) | 1 | |
| 9W7543 | 6 HINGE | 1 | |
| 0S0509 | 7 BOLT | 2 | |
| 5P1075 | 8 WASHER | 6 | |
| 9W5548 | 9 PLATE ASSEM. | 1 | |
| 9F2978 | NUT (WELD) | 3 | |
| 0L1351 | 10 BOLT | 6 | |
| 5M2894 | 11 WASHER | 2 | |
| 7T8778 | 12 BOLT | 1 | |
| 8B4624 | 13 SHIM | 1 | |
| 3B4610 | 14 COTTER PIN | 1 | |
| 9W9535 | 15 COVER ASSEM. | 1 | |
| 1F0748 | NUT (WELD) | 1 | |
| 8P0612 | 16 BRACKET | 2 | |
| 6K1049 | 17 HINGE | 1 | |
| 1S6385 | 18 LUG | 1 | |
| 9M3835 | 19 LATCH ASSEM. | 2 | |
| 3B4607 | 20 COTTER PIN | 2 | |
| 2M5795 | 21 CLEVIS PIN | 2 | |
| 9W5546 | 22 PLATE ASSEM. | 1 | |
| 9F2978 | NUT (WELD) | 2 | |
| 9F6445 | NUT (WELD) | 1 |
