System And Components
STARTING MOTOR (3Y6305 N/S)--Robert BoschPart of 4N3181--Page 87
Group No: STARTING
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3T0849 | 1 BOLT | 12 | |
| 3T7022 | 2 HOUSING ASSEM. | 1 | |
| 3T0850 | 3 SCREW | 8 | |
| 3T7021 | 4 PLATE | 1 | |
| 3T0867 | 5 ARMATURE ASSEM. | 1 | |
| 3T7020 | 6 WASHER | 1 | |
| 3T0847 | 7 SCREW | 4 | |
| 7X0562 | 8 WASHER | 4 | |
| 8T4244 | 9 NUT | 4 | |
| 4N4517 | 10 DRIVE ASSEM. | 1 | |
| 5C2874 | 11 NUT | 5 | |
| 8T4970 | 12 BOLT | 4 | |
| 8T4205 | 13 WASHER | 4 | |
| 5C2890 | 14 NUT | 2 | |
| 1H3244 | 15 LOCKWASHER | 2 | |
| 3T0864 | 16 HOUSING ASSEM. | 1 | |
| 3T0842 | BEARING ASSEM. | 1 | |
| 3T0863 | 17 LEVER | 1 | |
| 3T0862 | 18 PLATE ASSEM. | 1 | |
| 3T7025 | 19 COVER | 1 | |
| 8F1434 | 20 LOCKWASHER | 1 | |
| 6V9673 | 21 SCREW | 4 | |
| 7X0620 | 22 WASHER | 4 | |
| 3T0858 | 23 SPRING | 4 | |
| 3T0865 | 24 COIL ASSEM. | 1 | |
| 3T4716 | 25 WIRE ASSEM. | 1 | |
| 2L8071 | TERMINAL | 1 | |
| 2L8067 | TERMINAL | 1 | |
| 9X0332 | 26 SOLENOID ASSEM. | 1 | |
| 3T0844 | KIT (BRUSH) | 1 | |
| 7T2339 | LEVER KIT | 1 | |
| 3T7017 | KIT (BEARING) | 1 | |
| 3T2768 | KIT (SEAL) | 1 | |
| 3T2769 | KIT (HARDWARE) | 1 |
