System And Components
2P6486 CYLINDER HEAD GPENGINE S/N 47V15899-UP
Group No: 2P6486
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7S7144 | 1 SPRING-VALVE | 12 | |
| 1W5300 | 2 ROTOCOIL AS (EACH INCL) | 12 | |
| 6N7174 | SHIELD-OIL | 1 | |
| 8N7782 | ROTOCOIL AS | 1 | |
| 2A4429 | 3 LOCK-RETAINER | 24 | |
| 6N8120 | 4 CYLINDER HEAD AS | 1 | |
| 0S1594 | 5 BOLT | 4 | |
| 5M2894 | 6 WASHER | 4 | |
| 1P6367 | 7 COVER | 1 | |
| 5S6735 | 8 GASKET | 1 | |
| 3B0623 | 9 PLUG-CUP | 6 | |
| 3S8313 | 10 PLUG-CUP | 7 | |
| 1S3062 | 11 DIRECTOR-WATER | 18 | |
| 2B0858 | 12 PLUG-PIPE | 3 | |
| 7N4448 | 13 INSERT (INTAKE) | 6 | |
| 5S7221 | 14 INSERT (EXHAUST) | 6 | |
| 2P1262 | 15 GUIDE-VALVE | 12 | |
| 5M2667 | 16 GASKET-CHAMBER 4.93MM(.194IN)THK | 6 | |
| 2S8959 | GASKET-CHAMBER 5.66MM(.223IN)THK | 6 | |
| 2S8960 | GASKET-CHAMBER 6.3MM(.248IN)THK | 6 | |
| 7S3206 | 17 SEAL-O-RING | 6 | |
| 8S3970 | 18 CHAMBER AS | 6 | |
| 6N7263 | 19 GASKET-CYLINDER HEAD | 1 | |
| 5S6452 | 20 VALVE-INLET | 6 | |
| 5S7232 | 21 VALVE-EXHAUST | 6 |
