System And Components
5T1283 LINES GP-FUEL-PART 2 OF 2
Group No: 5T1283
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V8625 | 1 ELBOW | 2 | |
| 6V8398 | 2 SEAL-0-RING | 11 | |
| 3K0360 | 3 SEAL-O-RING | 3 | |
| 8T0081 | 4 VALVE-BALL | 1 | |
| 8T2502 | 5 BOLT | 4 | |
| 8T4896 | 6 WASHER-HARD | 4 | |
| 8W0552 | 7 TUBE AS | 1 | |
| 6V8721 | 8 ELBOW-FACE SEAL | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8981 | 9 ELBOW | 2 | |
| 6V9169 | 10 NUT-BULKHEAD | 4 | |
| 6V9353 | 11 UNION-BULKHEAD | 1 | |
| 7J9108 | 12 SEAL-O-RING 16.23MM (.639IN) I.D. | 5 | |
| 8W0553 | 13 TUBE AS | 1 | |
| 5P8874 | 14 ADAPTER | 1 | |
| 3J1907 | 15 SEAL | 2 | |
| 9S4182 | 16 PLUG | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V9873 | 17 CONNECTOR-SPECIAL | 1 | |
| 8W0554 | 18 TUBE AS | 1 | |
| 8W0551 | 19 TUBE AS | 1 | |
| 6V8995 | 20 UNION-BULKHEAD | 1 | |
| 6V9170 | 21 NUT-BULKHEAD | 2 | |
| 6V8982 | 22 ELBOW-90 DEGREE | 1 | |
| 2H3924 | 23 LOCKWASHER | 2 | |
| 6V8996 | 24 UNION-BULKHEAD | 1 | |
| 6V8994 | 25 UNION-BULKHEAD | 1 | |
| 6V8397 | 26 SEAL-O-RING | 3 | |
| 6V9168 | 27 NUT | 2 | |
| 8W3102 | 28 HOSE AS | 1 | |
| 8W3103 | 29 HOSE AS | 1 | |
| 6V9850 | 30 ELBOW | 1 | |
| 2H3922 | 31 LOCKWASHER | 2 |
