System And Components
5T0650 CONTROL GP-STEERING-PART 2 OF 2S/N 2PD740-UP
Group No: 5T0650
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8H4320 | 1 BALL BEARING | 2 | |
| 6G0009 | 2 BRACKET | 2 | |
| 0310215 | 3 BOLT-SELF LOCKING | 3 | |
| 5P0537 | WASHER | 3 | |
| 2B5886 | 4 BEARING-SLEEVE | 1 | |
| 3B5301 | 5 COTTER | 1 | |
| 3S4111 | 6 BUSHING (.7545 DIA) | 2 | |
| 2K7979 | BEARING (1.0035 DIA) | 2 | |
| 6F9254 | 7 WASHER-THRUST | 2 | |
| 4L9337 | 8 BOLT | 1 | |
| 8T4896 | 9 WASHER-HARD | 8 | |
| 6G8352 | 10 SPRING | 1 | |
| 3P9029 | 11 KEY | 1 | |
| 6G8278 | 12 SEAL AS | 1 | |
| 9D3868 | 13 SCREW | 4 | |
| 6G7802 | 14 PLATE | 1 | |
| 4L6454 | 15 BOLT | 7 | |
| 6K8162 | 16 RING-RETAINING | 1 | |
| 5H6480 | 17 RING-RETAINING | 1 | |
| 6V3812 | 18 BALL BEARING | 1 | |
| 5M6213 | 19 PLUG | 2 |
