System And Components
119-1147 PUMP & LINES GP-WATER SPRAYS/N PNM286-UP
Group No: 119-1147
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3777287 | 1 PUMP & MOTOR GP-WATER SPRAY | 1 | |
| 4M6425 | 2 BOLT (5/16-18X1-IN) | 4 | |
| 8T4224 | 3 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 3B7255 | 4 BUSHING-REDUCER | 1 | |
| 0032143 | 5 ELBOW | 2 | |
| 7R4183 | 6 GAUGE-WATER PRESSURE | 1 | |
| 8C7993 | 7 COVER-DUST | 1 | |
| 5R5560 | 8 COUPLING AS | 1 | |
| 5R7817 | SEAL | 1 | |
| 5R7818 | RING-BACKUP | 1 | |
| 9N3666 | 9 VALVE-MANUAL | 1 | |
| 6V8189 | 10 NUT (5/16-18-THD) | 4 | |
| 0308370 | 11 ADAPTER-PIPE | 1 | |
| 3B7731 | 12 ELBOW | 2 | |
| 9U7015 | 13 FITTING | 2 | |
| 3B7722 | 14 BUSHING-PIPE | 1 | |
| 0039014 | 15 ELBOW | 1 | |
| 1488407 | 16 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 7X0264 | 18 BOLT (1/4-20X2.5-IN) | 2 | |
| 7R7951 | 19 PLATE | 1 | |
| 1162001 | 20 STRAINER GP-WATER | 1 | |
| 3B7744 | 21 FITTING | 1 | |
| 0025299 | 23 TEE-PIPE | 1 | |
| 0046683 | 24 FITTING | 1 | |
| 5D1707 | 25 FITTING | 1 | |
| 8D9448 | 26 BOSS | 1 | |
| 8C6867 | 27 CONNECTOR | 1 | |
| 4J5477 | 28 SEAL-O-RING | 1 | |
| 1488337 | 29 CONNECTOR AS | 1 | |
| 8C6866 | CONNECTOR | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1448245 | 30 HOSE AS | 1 | |
| 5P0765 | 31 HOSE (200-CM) | ||
| 7C4354 | 32 CLIP | 1 | |
| 9B7237 | 33 BOLT (3/8-16X1.25-IN) | 1 | |
| 5P1075 | 34 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 3K6060 | 35 LOCKNUT (3/8-16-THD) | 1 | |
| 5D1026 | 36 CLAMP-BAND | 4 | |
| 7R7939 | 37 CLAMP-PIPE | 2 | |
| 8T4205 | 38 WASHER-HARD (7.2X14.5X2-MM THK) | 2 |
