482-5132 KIT-WATER TANK & MOUNTINGS/N WS51-UP

Group No: 482-5132
Part NumberPart NameQty
3S20931 STRAP-CABLE3
7K11812 STRAP-CABLE2
8T07373 VALVE-SHUTOFF1
11620014 STRAINER GP-WATER1
12418985 COUPLING-PERMANENT1
12419166 COUPLING-PERMANENT1
12419177 COUPLING-PERMANENT2
16625518 TANK GP-WATER1
16625579 PLATE1
166255810 COUPLING1
166255911 BRACKET2
218584712 PLATE1
345607313 PLATE2
346183214 PUMP GP-DIAPHRAGM1
346183615 BRACKET AS1
9R8429BOSS (M16X2X31.8-MM)4
356611216 HARNESS AS-WORK TOOL1
1028802KIT-RECEPTACLE (2-PIN)1
8T8729PIN-CONNECTOR (16-GA TO 20-GA)2
8T8730SOCKET-CONNECTOR (16-GA TO 20-GA)2
1552270KIT-CONNECTING PLUG (2-PIN)1
433969317 BRACKET1
433969418 PLATE2
433969519 PLATE2
439499120 SPACER (19X27X22-MM THK)8
003214321 ELBOW1
095091222 CLIP3
111462723 SCREW-MACHINE (M6X1X30-MM)4
119385924 SCREW-PAN HEAD (10-16X0.75-IN)6
129317825 LOCKNUT (M6X1-THD)4
156617526 CLIP (LADDER)1
178362027 STRAP-DUAL CLAMP4
266331428 BOLT-FLANGE HEAD (M6X1X20.5-MM)3
266331629 BOLT-FLANGE HEAD (M10X1.5X25-MM)2
3B725530 BUSHING-REDUCER1
3H765431 WASHER-HARD (13.5X22.5X3-MM THK)2
4M006132 BOLT (5/16-18X0.75-IN)2
5P824633 WASHER-HARD (15.5X29X3-MM THK)2
7X049534 ADAPTER1
8T412235 WASHER-HARD (17X32X3.5-MM THK)24
8T413236 NUT (M16X2-THD)8
8T414037 BOLT (M16X2X60-MM)8
8T418338 BOLT (M12X1.75X40-MM)2
8T420539 WASHER-HARD (7.2X14.5X2-MM THK)3
8T424440 NUT (M12X1.75-THD)2
8T477941 BOLT (M16X2X35-MM)4
8T733842 BOLT (M16X2X45-MM)4
8T797143 WASHER-HARD (13.5X25.5X5-MM THK)4
9X203844 WASHER (7X19X2-MM THK)4
167060845 SEAL (82-CM)
9X209246 TRIM-EDGE (12-CM EACH)
