145-8901 BATTERY & WIRING GPS/N 3YW1-1829

Group No: 145-8901
Part NumberPart NameQty
3T31321 SWITCH AS-LIMIT (HIGH SPEED TRAVEL)1
2H3922LOCKWASHER1
6V8363SCREW (10-32X0.312-IN)2
6V8370NUT-HEX (3/4-32-THD)1
8F1434LOCKWASHER2
9X0199BOOT-SWITCH1
7T06352 HORN AS (12-VOLT)1
8C7581SCREW-MACHINE (M4X0.7X8-MM)1
9B7233LOCKWASHER1
0966166WASHER-HARD (4.5X9X1-MM THK)1
8I46413 STRAP-GROUND1
8T87994 BOOT (RED)3
9G36955 PLUG-SEAL9
9W14426 FUSE (10-AMPERE)8
08973657 WASHER (7X24X10-MM THK)1
11516158 RELAY AS (12-VOLT)(START AID)1
11516158A RELAY AS (12-VOLT)(BOOM LOWER)1
11516158B RELAY AS (12-VOLT)(START)1
11516158C RELAY AS (12-VOLT)(START DISABLE)1
11516158D RELAY AS (12-VOLT)(HYDRAULIC DISABLE)1
11516158E RELAY AS (12-VOLT)(FLOOD LAMP)1
12006679 SENDER-TEMPERATURE (COOLANT)1
121369910 SEAL1
138492311 SHAFT1
139497212 SPACER AS1
143226713 GAUGE GP-CLUSTER1
144231714 BOOT1
144232115 PLATE1
154318916 HARNESS AS (FRAME)1
1028802KIT-RECEPTACLE (2-PIN)2
1028804KIT-RECEPTACLE (4-PIN)1
1028806KIT-RECEPTACLE (8-PIN)1
1552260KIT-CONNECTING PLUG (3-PIN)1
1552270KIT-CONNECTING PLUG (2-PIN)4
1552271KIT-CONNECTING PLUG (4-PIN)1
154319017 HARNESS AS-ENGINE1
1028801KIT-RECEPTACLE (12-PIN)1
1028805KIT-RECEPTACLE (6-PIN)1
1552270KIT-CONNECTING PLUG (2-PIN)1
1552271KIT-CONNECTING PLUG (4-PIN)1
154319318 HARNESS AS-PANEL (FUSE PANEL)1
1028802KIT-RECEPTACLE (2-PIN)1
1552255KIT-CONNECTING PLUG (12-PIN)3
1552260KIT-CONNECTING PLUG (3-PIN)1
1552265KIT-CONNECTING PLUG (8-PIN)1
1552270KIT-CONNECTING PLUG (2-PIN)1
1552274KIT-CONNECTING PLUG (6-PIN)2
154319419 CABLE AS1
1S7252TERMINAL-CABLE (00-GA, 3/8-IN SCREW)(FOR 3/8 IN BOLT)1
3S6049TERMINAL AS-BATTERY (POSITIVE)1
1M6119BOLT (5/16-18X1.375-IN)1
1M6120NUT (5/16-18-THD)1
5P0761CABLE (00-GA, RED)(70CM)
8N0869COVER-TERMINAL (RED)1
8N1725COVER AS-TERMINAL (RED)1
154319520 CABLE AS1
1S7251TERMINAL-CABLE (00-GA, 1/2-IN SCREW)(FOR 1/2 IN BOLT)1
3S6050TERMINAL AS-BATTERY (NEGATIVE)1
1M6119BOLT (5/16-18X1.375-IN)1
1M6120NUT (5/16-18-THD)1
5P0747CABLE (00-GA, BLACK)(80CM)
7N5274COVER AS-TERMINAL (BLACK)1
154319721 SWITCH GP-START (KEY)1
158783322 WIRE AS-SWITCH (SPEED SELECT)(TWO SPEED)1
166696623 BRACKET1
168790824 SWITCH GP-MAGNETIC (12-VOLT)(MAIN POWER)1
3E3362WEDGE-PLUG LOCK (2-PIN)1
4F2294NUT-JAM (5/16-24-THD)2
6V8186NUT-FULL (5/16-24-THD)2
102880225 KIT-RECEPTACLE (2-PIN)1
102880326 KIT-RECEPTACLE (3-PIN)1
102880427 KIT-RECEPTACLE (4-PIN)1
4P758128 CLIP1
4P813429 CLIP1
5C287430 NUT (M5X0.8-THD)6
5C831231 NUT (M4X0.7-THD)2
5C955332 BOLT (M6X1X16-MM)2
5L450733 SCREW-MACHINE (10-32X0.875-IN)4
6V735734 BOLT (M6X1X25-MM)1
6V967235 SCREW-MACHINE (M4X0.7X16-MM)2
6V967436 SCREW-MACHINE (M5X0.8X14-MM)6
7X253737 BOLT (M8X1.25X35-MM)1
8C361238 BATTERY (12-VOLT)(12 VOLT)1
8T413339 NUT (M10X1.5-THD)1
8T417140 BOLT (M6X1X12-MM)12
8T420541 WASHER-HARD (7.2X14.5X2-MM THK)9
8T422342 WASHER-HARD (13.5X25.5X3-MM THK)1
8T422443 WASHER-HARD (8.8X16X2-MM THK)1
8T424444 NUT (M12X1.75-THD)1
9H195845 CIRCUIT BREAKER GP (20-AMPERE)1
9S017446 CIRCUIT BREAKER AS (60-AMPERE)2
7K118147 STRAP-CABLE11
