System And Components
145-8901 BATTERY & WIRING GPS/N BFA1758-2981; BDH789-1029; 3YW3340-4240
Group No: 145-8901
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7T0635 | 1 HORN AS (12-VOLT) | 1 | |
| 8C7581 | SCREW-MACHINE (M4X0.7X8-MM) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 0966166 | WASHER-HARD (4.5X9X1-MM THK) | 2 | |
| 8I4641 | 2 STRAP-GROUND | 1 | |
| 8T8737 | 3 PLUG-SEAL | 9 | |
| 8T8799 | 4 BOOT (RED) | 1 | |
| 9W1442 | 5 FUSE (10-AMPERE) | 9 | |
| 0897365 | 6 WASHER (7X24X10-MM THK) | 1 | |
| 1068704 | 7 SUPPRESSOR AS-ARC | 1 | |
| 1092350 | 8 SWITCH AS-ROCKER (WARNING BEACON, POWER RECEP)(WIPER) | 1 | |
| 1151615 | 9 RELAY AS (12-VOLT)(BOOM LOWER) | 1 | |
| 1151615 | 9A RELAY AS (12-VOLT)(FLOOD LAMP) | 1 | |
| 1151615 | 9B RELAY AS (12-VOLT)(HYDRAULIC DISABLE) | 1 | |
| 1151615 | 9C RELAY AS (12-VOLT)(START) | 1 | |
| 1151615 | 9D RELAY AS (12-VOLT)(START AID) | 1 | |
| 1151615 | 9E RELAY AS (12-VOLT)(START DISABLE) | 1 | |
| 1200667 | 10 SENDER-TEMPERATURE (COOLANT) | 1 | |
| 1394972 | 11 SPACER AS | 1 | |
| 1543190 | 12 HARNESS AS-ENGINE | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 1543194 | 13 CABLE AS | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW)(FOR 1/2IN BOLT) | 1 | |
| 3S6049 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 5P0761 | CABLE (00-GA, RED)(70CM) | 1 | |
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 8N1725 | COVER AS-TERMINAL (RED) | 1 | |
| 1543195 | 14 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW)(FOR 1/2IN BOLT) | 1 | |
| 3S6050 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 5P0747 | CABLE (00-GA, BLACK)(80CM) | 1 | |
| 7N5274 | COVER AS-TERMINAL (BLACK) | 1 | |
| 1543197 | 15 SWITCH GP-START (KEY) | 1 | |
| 1687908 | 16 SWITCH GP-MAGNETIC (12-VOLT)(MAIN POWER) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 3E3362 | WEDGE-PLUG LOCK (2-PIN) | 1 | |
| 4F2294 | NUT-JAM (5/16-24-THD) | 2 | |
| 6V8186 | NUT-FULL (5/16-24-THD) | 2 | |
| 1863736 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1712208 | 17 CIRCUIT BREAKER AS (60-AMPERE) | 2 | |
| 6V8187 | NUT (1/4-28-THD) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 1H3244 | LOCKWASHER | 2 | |
| 1754280 | 18 BATTERY (12-VOLT)(500 CCA) | 1 | |
| 1876495 | 19 HARNESS AS-PANEL (FUSE PANEL) | 1 | |
| 9W2035 | BLOCK-FUSE | 3 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 2 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 3 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1552265 | KIT-CONNECTING PLUG (8-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 2 | |
| 1912272 | 20 BRACKET | 1 | |
| 2032311 | 21 GAUGE GP-CLUSTER | 1 | |
| 2081196 | 22 HARNESS AS (FRAME) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | ||
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 4 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 1293178 | 23 LOCKNUT (M6X1-THD) | 2 | |
| 1471380 | 24 SWITCH AS-FOOT (TWO SPEED) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1939141 | 25 COVER-TERMINAL | 2 | |
| 1028802 | 26 KIT-RECEPTACLE (2-PIN) | 1 | |
| 1028803 | 27 KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028804 | 28 KIT-RECEPTACLE (4-PIN) | 1 | |
| 4P7581 | 29 CLIP | 1 | |
| 4P8134 | 30 CLIP | 1 | |
| 5C2874 | 31 NUT (M5X0.8-THD) | 6 | |
| 5C8312 | 32 NUT (M4X0.7-THD) | 2 | |
| 5C9553 | 33 BOLT (M6X1X16-MM) | 4 | |
| 5L4507 | 34 SCREW-MACHINE (10-32X0.875-IN) | 4 | |
| 6V1322 | 35 BOLT (1/4-20X0.375-IN) | 2 | |
| 6V7357 | 36 BOLT (M6X1X25-MM) | 1 | |
| 6V9672 | 37 SCREW-MACHINE (M4X0.7X16-MM) | 2 | |
| 6V9674 | 38 SCREW-MACHINE (M5X0.8X14-MM) | 6 | |
| 7X2537 | 39 BOLT (M8X1.25X35-MM) | 1 | |
| 8T4133 | 40 NUT (M10X1.5-THD) | 1 | |
| 8T4171 | 41 BOLT (M6X1X12-MM) | 8 | |
| 8T4205 | 42 WASHER-HARD (7.2X14.5X2-MM THK) | 11 | |
| 8T4223 | 43 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T4224 | 44 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T4244 | 45 NUT (M12X1.75-THD) | 1 | |
| 9H1958 | 46 CIRCUIT BREAKER GP (20-AMPERE) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 1973800 | 47 LOOM (65MM) | ||
| 1973800 | 47A LOOM (85MM) | ||
| 3S2093 | 48 STRAP-CABLE | 1 | |
| 7K1181 | 49 STRAP-CABLE | 13 |
