System And Components
Assembly
100%

212-8002 HOOD GPS/N 103207-UP

Group No: 212-8002
Part NumberPart NameQty
25246841 SEAL1
21280422 SEAL1
21474713 HOOD AS1
21280363A DOOR AS1
1728120HINGE3
7T10993B LINK13
8T34903C NUT-WELD (M10X1.5-THD)13
8T36123D NUT-WELD (M8X1.25-THD)2
8T41833E BOLT (M12X1.75X40-MM)5
6V95113F PLUG (1-3/16-12-THD)4
8T38513G BOSS-WELD (M10X1.5X17.5-MM)1
21475154 STRIP1
21475175 STRIP1
21475186 SEAL1
21475197 PLATE1
21475208 SEAL1
21475219 STRIP1
224084410 COVER2
6V768811 LOCKNUT (M20X2.5-THD)2
7X256512 BOLT (M20X2.5X100-MM)2
8T422313 WASHER-HARD (13.5X25.5X3-MM THK)5
8T413314 NUT (M10X1.5-THD)4
8T419515 BOLT (M10X1.5X30-MM)7
8T419616 BOLT (M10X1.5X35-MM)5
8T420017 BOLT (M8X1.25X16-MM)2
8T424418 NUT (M12X1.75-THD)5
8T412119 WASHER-HARD (11X21X2.5-MM THK)10
252468520 STRIP1
266665221 COVER AS1
8T418522 BOLT (M10X1.5X50-MM)5
251763223 PLATE2
251763124 PLATE1
158305925 EYEBOLT (M8X1.25X100-MM)2
150531126 LOCKWASHER3
6V894927 NUT (M10X1.5-THD)3
8T489628 WASHER-HARD (10.2X18.5X2.5-MM THK)2
