System And Components
311-2345 PAN GP-OILS/N CSD1-11322
Group No: 311-2345
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I1201 | 1 SEAL-O-RING | 1 | |
| 1189145 | 2 CONNECTOR | 1 | |
| 1535933 | 3 SEAL (ENGINE OIL FILL) | 1 | |
| 1535936 | 4 WASHER (8.2X14.5X1-MM) | 2 | |
| 1536412 | 5 WASHER | 2 | |
| 1536833 | 6 BOLT (M6X1X13-MM) | 30 | |
| 1536835 | 7 SEAL-O-RING | 1 | |
| 1536838 | 8 BOLT AS | 3 | |
| 1536841 | 9 SEAL-O-RING | 2 | |
| 1536848 | 10 COVER | 1 | |
| 1536849 | 11 SPRING | 1 | |
| 1536850 | 12 COLLAR | 1 | |
| 1536851 | 13 CLIP | 1 | |
| 1536853 | 14 SEAL-O-RING | 1 | |
| 1536879 | 15 STUD-HOLLOW | 1 | |
| 1536881 | 16 BOLT (M8X1.25X18-MM) | 1 | |
| 1541942 | 17 VALVE-RELIEF | 1 | |
| 1542353 | 18 TUBE AS-OIL | 1 | |
| 1558084 | 19 WASHER | 1 | |
| 1567347 | 20 TUBE AS | 1 | |
| 1604150 | 21 SHIM (0.1-MM THK) | 1 | |
| 1604151 | SHIM (0.15-MM THK) | 1 | |
| 1604152 | SHIM (0.2-MM THK) | 1 | |
| 1604153 | SHIM (0.5-MM THK) | 1 | |
| 1647619 | 22 SEAL-O-RING | 1 | |
| 1982663 | 23 BOLT (M14X1.5X30-MM) | 1 | |
| 2152605 | 24 GASKET | 1 | |
| 2177352 | 25 COVER-VALVE | 1 | |
| 2177358 | 26 CAP-OIL FILLER (ENGINE)(ENGINE) | 1 | |
| 2182333 | 27 PAN-OIL | 1 | |
| 2182334 | 28 PLUG-DRAIN (ENGINE OIL) | 1 | |
| 2201523 | 29 FILTER AS-ENGINE OIL | 1 | |
| 2318920 | 30 BOLT | 1 | |
| 3124560 | 31 VALVE-DRAIN | 1 | |
| 2520787 | 32 SEAL-O-RING | 1 | |
| 2520788 | 33 BASE-OIL FILTER | 1 | |
| 2934781 | 34 GAUGE AS-OIL LEVEL (DIPSTICK) (ENGINE) | 1 | |
| 2965162 | 35 ROTOR | 1 | |
| 3050584 | 36 STRAINER (ENGINE OIL) | 1 | |
| 3162275 | 37 TUBE-OIL SUCTION | 1 | |
| 3112349 | 38 WASHER | 1 |
