System And Components
238-1269 GOVERNOR GP
Group No: 238-1269
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C2890 | 1 NUT (M6X1-THD) | 1 | |
| 1395511 | 2 CAP (TAMPER RESISTANT) | 1 | |
| 1535960 | 3 NUT (M6X1-THD) | 1 | |
| 1537983 | 4 PIN | 1 | |
| 1537987 | 5 WASHER | 1 | |
| 1541396 | 6 CLIP | 1 | |
| 1541401 | 7 ARM | 1 | |
| 1541403 | 8 SEAL-O-RING | 1 | |
| 1541408 | 9 WASHER (8.4X15.5X1.6-MM THK) | 1 | |
| 1541410 | 10 SEAL-O-RING | 2 | |
| 1541411 | 11 CLIP | 1 | |
| 1541412 | 12 BRACKET | 1 | |
| 1541636 | 13 NUT (M8X1.25-THD) | 2 | |
| 1541637 | 14 ARM | 1 | |
| 1541638 | 15 SEAL-O-RING | 1 | |
| 1541639 | 16 CLIP | 1 | |
| 3107139 | 17 SPRING | 1 | |
| 1558002 | 18 SPRING | 1 | |
| 1558009 | 19 BOLT | 1 | |
| 8T4971 | 20 BOLT (M6X1X30-MM) | 3 | |
| 1622207 | 21 NUT | 2 | |
| 1833570 | 22 LEVER | 1 | |
| 2497263 | 23 BOLT (M6X1X16-MM) | 2 | |
| 1919296 | 24 BOLT | 1 | |
| 1919297 | 25 NUT (M10X1.25-THD) | 1 | |
| 1977909 | 26 SHAFT | 1 | |
| 2005995 | 27 SPRING | 1 | |
| 2117739 | 28 KIT-CAP (TAMPER RESISTANT) | 1 | |
| 1919293 | 28A CAP-COVER | 1 | |
| 2177111 | 29 BOLT AS | 1 | |
| 1537987 | 29A WASHER | 1 | |
| 2120743 | 29B NUT | 1 | |
| 2120744 | 29C SEAL-O-RING | 1 | |
| 2120745 | 29D BOLT | 1 | |
| 2120747 | 29E RING-RETAINING | 1 | |
| 2177115 | 30 CAP (TAMPER RESISTANT) | 1 | |
| 2313821 | 31 LEVER AS | 1 | |
| 1541396 | 31A CLIP | 1 | |
| 1541399 | 31B WASHER | 1 | |
| 1541400 | 31C PIN | 1 | |
| 1833567 | 31D LEVER | 1 | |
| 2381266 | 32 LEVER | 1 |
