System And Components
246-3481 PAN GP-OILS/N CSD10860-11248
Group No: 246-3481
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2497264 | 2 VALVE-DRAIN (ENGINE OIL) | 1 | |
| 1535933 | 3 SEAL | 1 | |
| 1535936 | 4 WASHER (8.2X14.5X1-MM) | 2 | |
| 1536412 | 5 WASHER | 2 | |
| 1536833 | 6 BOLT (M6X1X13-MM) | 31 | |
| 1536835 | 7 SEAL-O-RING | 1 | |
| 1536838 | 8 BOLT AS | 2 | |
| 1536841 | 9 SEAL-O-RING | 2 | |
| 1536848 | 10 COVER | 1 | |
| 1536849 | 11 SPRING | 1 | |
| 1536850 | 12 COLLAR | 1 | |
| 1536851 | 13 CLIP | 1 | |
| 1536853 | 14 SEAL-O-RING | 1 | |
| 1536881 | 15 BOLT (M8X1.25X18-MM) | 1 | |
| 1541941 | 16 ROTOR | 1 | |
| 1541942 | 17 VALVE-RELIEF (OIL PUMP) | 1 | |
| 3124554 | 18 PAN-OIL | 1 | |
| 3050585 | 19 TUBE-OIL SUCTION | 1 | |
| 3050584 | 20 STRAINER (ENGINE OIL) | 1 | |
| 1542353 | 21 TUBE AS-OIL | 1 | |
| 1558084 | 22 WASHER | 1 | |
| 1604150 | 23 SHIM (0.1-MM THK) | 1 | |
| 1604151 | SHIM (0.15-MM THK) | 1 | |
| 1604152 | SHIM (0.2-MM THK) | 1 | |
| 1604153 | SHIM (0.5-MM THK) | 1 | |
| 2182334 | 25 PLUG-DRAIN (ENGINE OIL PAN) | 1 | |
| 2152605 | 27 GASKET | 1 | |
| 2177352 | 28 COVER-VALVE | 1 | |
| 2934781 | 29 GAUGE AS-OIL LEVEL (DIPSTICK) (ENGINE) | 1 | |
| 2177358 | 30 CAP-OIL FILLER (ENGINE) | 1 | |
| 2382685 | 31 TUBE AS | 1 | |
| 2201523 | 32 FILTER AS-ENGINE OIL | 1 |
