System And Components
317-0979 PUMP GP-WATERS/N CYP1-UP; CYS1-UP
Group No: 317-0979
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5D1026 | 1 CLAMP-BAND | 2 | |
| 1278281 | 2 CLIP | 1 | |
| 1535960 | 3 NUT (M6X1-THD) | 3 | |
| 1535961 | 4 BOLT (M6X1X35-MM) | 4 | |
| 1541817 | 5 PLUG | 1 | |
| 4394993 | 6 PLUG | 1 | |
| 1557984 | 7 WASHER (8.4X16X1.6-MM THK) | 1 | |
| 1806118 | 8 BOLT (M8X1.25X12-MM) | 1 | |
| 4256407 | 9 GASKET | 1 | |
| 2389137 | 10 CONNECTION | 1 | |
| 4722214 | 11 CONNECTOR | 1 | |
| 2451361 | 12 COOLER AS-OIL (ENGINE) | 1 | |
| 2451362 | 12A CONNECTOR | 1 | |
| 2451364 | 12B SEAL | 1 | |
| 2495541 | 13 REGULATOR-TEMPERATURE (82-DEG C) | 1 | |
| 4778793 | 14 HOUSING (THERMOSTAT) | 1 | |
| 2867496 | 15 HOSE-WATER | 1 | |
| 3081907 | 16 BOLT AS | 2 | |
| 4235611 | 17 GASKET | 1 | |
| 3710183 | 18 PUMP-WATER | 1 |
