System And Components
325-1494 DISPLAY GP-MONITOR -WORK AREA VISUAL SYSTEMS/N DBW1-UP
Group No: 325-1494
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0950736 | 1 SCREW-MACHINE (M5X0.8X10-MM) | 4 | |
| 1643765 | 2 RETAINER | 3 | |
| 2326692 | 3 SCREW (M6X1X20-MM) | 3 | |
| 2613223 | 4 CABLE AS-COMMUNICATION | 1 | |
| 3338153 | 5 CONNECTION AS | 1 | |
| 3437767 | 6 HARNESS AS-SENSOR | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 4 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(15-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 5 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 5 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 12 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 12 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 4 | |
| 2457434 | KIT-CONNECTING PLUG (10-PIN) | 1 | |
| 2354123 | TERMINAL (18-GA TO 20-GA) | 6 | |
| 4646047 | 7 MODULE GP-DISPLAY (WORK AREA VISUAL SYSTEM) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 5 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 3443847 | CABLE AS (DISPLAY) | 1 | |
| 3501079 | 8 SWITCH AS-ROCKER (24-VOLT)(WORK AREA VISUAL SYSTEM) | 1 | |
| 3657570 | 9 PLATE | 1 | |
| 4B4274 | 10 WASHER (5.5X13X1.2-MM THK) | 4 | |
| 7K1181 | 11 STRAP-CABLE | 14 |
