System And Components
450-3668 LINES GP-WATER -LOWERS/N 2GR8285-UP; C8T2446-UP
Group No: 450-3668
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W1475 | 1 ADAPTER-LINES | 1 | |
| 2N0876 | 2 GASKET | 1 | |
| 4W5095 | 3 BRACKET | 1 | |
| 4W5888 | 4 BONNET-OIL COOLER | 1 | |
| 4W5889 | 5 BONNET | 1 | |
| 4W5899 | 6 TUBE | 1 | |
| 4709509 | 7 PLATE | 1 | |
| 4W6034 | 8 BONNET-OIL COOLER | 1 | |
| 4W6084 | 9 SUPPORT | 1 | |
| 4W6094 | 10 PLATE AS | 1 | |
| 4W6095 | 11 PLATE | 1 | |
| 4W6112 | 12 TUBE AS | 1 | |
| 4W9495 | 13 BONNET | 1 | |
| 4W9812 | 14 TUBE | 1 | |
| 4W9839 | 15 GASKET | 1 | |
| 5P2909 | 16 PLUG | 1 | |
| 7E7209 | 17 RING-RETAINING | 2 | |
| 7N4932 | 18 GASKET | 2 | |
| 7N4945 | 19 GASKET | 1 | |
| 7S8767 | 20 GASKET | 2 | |
| 8N0386 | 21 FLANGE | 1 | |
| 8N7641 | 22 TUBE | 1 | |
| 9L6533 | 23 PIPE-COOLER OUTLET | 1 | |
| 9X6772 | 24 STRAP-CABLE | 1 | |
| 8F8151 | 25 VALVE-SHUTOFF (WATER LINES) | 2 | |
| 1246333 | 26 CLAMP AS | 4 | |
| 1537459 | 27 HOSE AS | 1 | |
| 2780539 | 28 HOUSING-OIL COOLER | 1 | |
| 2780540 | 29 BRACKET | 1 | |
| 2875707 | 30 BONNET | 1 | |
| 2875708 | 31 BONNET-OIL COOLER | 1 | |
| 2875709 | 32 ELBOW | 1 | |
| 3193813 | 33 BRACKET | 1 | |
| 0321267 | 34 CONNECTOR (STRAIGHT) | 1 | |
| 0321268 | 35 CONNECTOR (90-DEG) | 1 | |
| 1653931 | 36 BOLT (3/8-16X1.75-IN) | 5 | |
| 0S1585 | 37 BOLT (1/2-13X1.5-IN) | 11 | |
| 0S1587 | 38 BOLT (1/2-13X1.75-IN) | 2 | |
| 0S1588 | 39 BOLT (3/8-16X1.25-IN) | 6 | |
| 0S1590 | 40 BOLT (3/8-16X2-IN) | 2 | |
| 0S1594 | 41 BOLT (3/8-16X1-IN) | 14 | |
| 0T0065 | 42 BOLT (3/8-16X3.5-IN) | 2 | |
| 1A1460 | 43 BOLT (1/2-13X2-IN) | 6 | |
| 1A5183 | 44 BOLT (3/8-16X4.75-IN) | 4 | |
| 1B2886 | 45 BOLT (1/2-13X3.75-IN) | 1 | |
| 1D4706 | 46 BOLT (3/8-16X6-IN) | 2 | |
| 2885476 | 47 SEAL-O-RING | 4 | |
| 2A4639 | 48 BOLT (3/8-16X1.625-IN) | 2 | |
| 2B0941 | 49 SPACER (10.5X19X19-MM THK) | 1 | |
| 2W2399 | 50 COVER | 1 | |
| 3S8664 | 51 CLIP | 1 | |
| 4F2612 | 52 GASKET | 1 | |
| 4N1320 | 53 GASKET (ADAPTER) | 1 | |
| 5B2638 | 54 BOLT (3/8-16X5.25-IN) | 4 | |
| 5M2894 | 55 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 5P8210 | 56 SEAL-O-RING | 1 | |
| 5P8245 | 57 WASHER-HARD (13.5X25.5X3-MM THK) | 19 | |
| 6H1717 | 58 BOLT (1/2-13X1.125-IN) | 2 | |
| 6V5066 | 59 SEAL-O-RING | 2 | |
| 6V6609 | 60 SEAL-O-RING | 2 | |
| 7B3235 | 61 BOLT (1/2-13X1.375-IN) | 8 | |
| 7H2444 | 62 SEAL-O-RING | 2 | |
| 7W6534 | 63 PLUG-PIPE | 2 | |
| 8B9725 | 64 BOSS (17/32X1X1/4-IN THK) | 2 | |
| 8F8544 | 65 BOLT (3/8-16X6.25-IN) | 2 | |
| 8M0755 | 66 ADAPTER | 1 | |
| 8S0948 | 67 CLIP | 3 | |
| 8S9089 | 68 BOLT (1/2-13X4.5-IN) | 4 | |
| 8T6758 | 69 PLUG-PIPE (1/4-18-THD) | 2 | |
| 8T6761 | 70 PLUG-PIPE (1-11-1/2 NPT THD) | 1 | |
| 8T6767 | 71 PLUG-PIPE (3/8-18-THD) | 1 | |
| 9M8546 | 72 GASKET | 2 | |
| 9S1374 | 73 BOLT (1/2-13X8-IN) | 2 | |
| 9S4185 | 74 PLUG (3/4-16-THD) | 2 | |
| 9S8752 | 75 NUT-FULL (3/8-16-THD) | 5 | |
| 9X6458 | 76 WASHER-HARD (10.2X22.5X3-MM THK) | 8 | |
| 4805324 | 77 BRACKET | 1 | |
| 9S1366 | 78 BOLT (1/2-13X2.5-IN) | 4 | |
| 1F7958 | 79 NUT-FULL (1/2-13-THD) | 2 | |
| 1S4305 | 80 SPACER (0.531X1X0.56-IN THK) | 2 | |
| 4703068 | 81 BRACKET | 1 |
