System And Components
4W-6169 LINES GP-WATER -LOWERS/N 2GR7638-7836
Group No: 4W-6169
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W1475 | 1 ADAPTER-LINES | 1 | |
| 2B0941 | 2 SPACER (10.5X19X19-MM THK) | 1 | |
| 2N0876 | 3 GASKET | 1 | |
| 2W2399 | 4 COVER | 1 | |
| 2W7628 | 5 PLATE-DRAIN | 1 | |
| 4N1320 | 6 GASKET (ADAPTER) | 1 | |
| 4W5095 | 7 BRACKET | 1 | |
| 4W5888 | 8 BONNET-OIL COOLER | 1 | |
| 4W5889 | 9 BONNET | 1 | |
| 4W5899 | 10 TUBE | 1 | |
| 4W5901 | 11 SUPPORT AS | 1 | |
| 4W6034 | 12 BONNET-OIL COOLER | 1 | |
| 4W6084 | 13 SUPPORT | 1 | |
| 4W6094 | 14 PLATE AS | 1 | |
| 4W6095 | 15 PLATE | 1 | |
| 4W6112 | 16 TUBE AS | 1 | |
| 4W9495 | 17 BONNET | 1 | |
| 4W9812 | 18 TUBE | 1 | |
| 4W9839 | 19 GASKET | 1 | |
| 5P2909 | 20 PLUG | 1 | |
| 7N3298 | 22 COVER-BLOCK | 2 | |
| 7N4932 | 23 GASKET | 2 | |
| 7N4939 | 24 BONNET-OIL COOLER | 1 | |
| 7N4940 | 25 BRACKET | 1 | |
| 7N4945 | 26 GASKET | 4 | |
| 7S8767 | 27 GASKET | 2 | |
| 8N0386 | 28 FLANGE | 1 | |
| 8N7641 | 29 TUBE | 1 | |
| 9L6533 | 30 PIPE-COOLER OUTLET | 1 | |
| 9X6772 | 31 STRAP-CABLE | 1 | |
| 0057889 | 32 VALVE AS-DRAIN (WATER LINES) | 2 | |
| 1246333 | 33 CLAMP AS | 4 | |
| 1537459 | 34 HOSE AS | 1 | |
| 2875707 | 35 BONNET | 1 | |
| 2875708 | 36 BONNET-OIL COOLER | 1 | |
| 2875709 | 37 ELBOW | 1 | |
| 2885476 | 38 SEAL-O-RING | 4 | |
| 0321267 | 39 CONNECTOR (STRAIGHT) | 1 | |
| 0321268 | 40 CONNECTOR (90-DEG) | 1 | |
| 0S1571 | 41 BOLT (3/8-16X1.75-IN) | 7 | |
| 0S1585 | 42 BOLT (1/2-13X1.5-IN) | 11 | |
| 0S1587 | 43 BOLT (1/2-13X1.75-IN) | 2 | |
| 0S1588 | 44 BOLT (3/8-16X1.25-IN) | 4 | |
| 0S1590 | 45 BOLT (3/8-16X2-IN) | 2 | |
| 0S1594 | 46 BOLT (3/8-16X1-IN) | 18 | |
| 0S1595 | 47 BOLT (1/2-13X1.25-IN) | 4 | |
| 0T0065 | 48 BOLT (3/8-16X3.5-IN) | 2 | |
| 1A1460 | 49 BOLT (1/2-13X2-IN) | 6 | |
| 1A5183 | 50 BOLT (3/8-16X4.75-IN) | 4 | |
| 1B2886 | 51 BOLT (1/2-13X3.75-IN) | 1 | |
| 1D4706 | 52 BOLT (3/8-16X6-IN) | 2 | |
| 1F7958 | 53 NUT-FULL (1/2-13-THD) | 4 | |
| 2A4639 | 54 BOLT (3/8-16X1.625-IN) | 2 | |
| 3B1915 | 55 BOLT (3/8-16X1.375-IN) | 4 | |
| 4F2612 | 56 GASKET | 1 | |
| 5B2638 | 57 BOLT (3/8-16X5.25-IN) | 4 | |
| 5M2894 | 58 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 5P8210 | 59 SEAL-O-RING | 1 | |
| 5P8245 | 60 WASHER-HARD (13.5X25.5X3-MM THK) | 23 | |
| 6H1717 | 61 BOLT (1/2-13X1.125-IN) | 2 | |
| 6V5066 | 62 SEAL-O-RING | 2 | |
| 6V6609 | 63 SEAL-O-RING | 2 | |
| 7B3235 | 64 BOLT (1/2-13X1.375-IN) | 8 | |
| 7H2444 | 65 SEAL-O-RING | 2 | |
| 8F8544 | 66 BOLT (3/8-16X6.25-IN) | 2 | |
| 8M0755 | 67 ADAPTER | 1 | |
| 8S0948 | 68 CLIP | 3 | |
| 8S9089 | 69 BOLT (1/2-13X4.5-IN) | 4 | |
| 8T6758 | 70 PLUG-PIPE (1/4-18-THD) | 2 | |
| 8T6761 | 71 PLUG-PIPE (1-11-1/2 NPT THD) | 4 | |
| 8T6767 | 72 PLUG-PIPE (3/8-18-THD) | 3 | |
| 9M8546 | 73 GASKET | 2 | |
| 9S1374 | 74 BOLT (1/2-13X8-IN) | 2 | |
| 9S4185 | 75 PLUG (3/4-16-THD) | 2 | |
| 0S1594 | 80 BOLT (3/8-16X1-IN) | 1 | |
| 5M2894 | 81 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8T6758 | 82 PLUG-PIPE (1/4-18-THD) | 1 | |
| 7E7209 | RING-RETAINING | 2 |
