System And Components
113-3650 WIRING GP-POWER TRAINS/N 9AR1-1175
Group No: 113-3650
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3J1907 | 1 SEAL-O-RING | 1 | |
| 3K0360 | 2 SEAL-O-RING | 2 | |
| 6V2455 | 3 SENSOR GP-SPEED (ENGINE) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 9X1386 | SLEEVE (14CM) | ||
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 7K1181 | 4 STRAP-CABLE | 27 | |
| 7V5628 | 5 PLATE (TOP) | 1 | |
| 7V6089 | 6 CLAMP | 2 | |
| 7W1238 | 7 SWITCH AS-PRESSURE (ENGINE OIL) | 1 | |
| 8T8799 | 8 BOOT (RED) | 5 | |
| 9W1795 | 9 BOOT | 1 | |
| 1043007 | 10 SENDER AS-TEMPERATURE | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 1183534 | 11 SWITCH GP-MAGNETIC (24-VOLT)(START RELAY) | 1 | |
| 1185144 | 12 SENDER AS-TEMPERATURE | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 1313201 | 13 BOOT | 2 | |
| 1353327 | 14 PLATE AS | 1 | |
| 1471773 | 15 CIRCUIT BREAKER AS (30-AMPERE) | 1 | |
| 8T0328 | WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 6V8378 | NUT (10-32-THD) | 2 | |
| 8F1434 | LOCKWASHER | 2 | |
| 1503597 | 16 PLATE AS | 1 | |
| 1545206 | 17 HARNESS AS-ENGINE | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 4 | |
| 1712208 | 18 CIRCUIT BREAKER AS (60-AMPERE) | 2 | |
| 1H3244 | LOCKWASHER | 2 | |
| 6V8187 | NUT (1/4-28-THD) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 1720329 | 19 HARNESS AS-TRANSMISSION | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 1744312 | 20 SWITCH AS-PRESSURE (BRAKE) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 3E3371 | WEDGE-RECEPTACLE LOCK (3-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1488331 | 21 CONNECTOR AS | 1 | |
| 3Y2888 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4B4274 | 22 WASHER (5.5X13X1.2-MM THK) | 6 | |
| 4P7581 | 23 CLIP (LADDER) | 5 | |
| 4P8134 | 24 CLIP (LADDER) | 14 | |
| 5L4507 | 25 SCREW-MACHINE (10-32X0.875-IN) | 4 | |
| 6D4244 | 26 CLIP (LOOP) | 1 | |
| 7X2534 | 27 BOLT (M6X1X50-MM) | 2 | |
| 7X2552 | 28 BOLT (M16X2X30-MM) | 1 | |
| 8M2773 | 29 CLIP (LOOP) | 1 | |
| 8T4121 | 30 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4122 | 31 WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 8T4136 | 32 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4137 | 33 BOLT (M10X1.5X20-MM) | 5 | |
| 8T4138 | 34 BOLT (M6X1X20-MM) | 2 | |
| 8T4189 | 35 BOLT (M8X1.25X20-MM) | 3 | |
| 8T4224 | 36 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9X8256 | 37 WASHER (6.6X12X2-MM THK) | 2 | |
| 9X8486 | 38 SCREW-MACHINE (8-32X0.75-IN) | 2 |
