258-4054 SEAT GP-SUSPENSION -MECHANICALS/N TMW1-UP
Group No: 258-4054
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8L8413 | 1 STRAP-CABLE (WHITE) | 2 | |
| 2735915 | 2 PLATE | 1 | |
| 2739611 | 3 SUSPENSION GP-SEAT (MECHANICAL) | 1 | |
| 2932872 | 4 HARNESS AS-SWITCH | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 2115358 | CONDUIT-FLEXIBLE (55-CM) | ||
| 3057092 | 5 SLIDE AS (LATCHING) | 1 | |
| 3057093 | 6 SLIDE AS (SLAVE) | 1 | |
| 3057096 | 7 SEAT GP | 1 | |
| 3072955 | 8 LANYARD | 2 | |
| 0314155 | 9 LOCKNUT (5/16-18-THD) | 4 | |
| 1P1210 | 10 WASHER (0.391X0.812X0.067-IN THK) | 4 | |
| 4M0061 | 11 BOLT (5/16-18X0.75-IN) | 4 | |
| 6V7687 | 12 LOCKNUT (M12X1.75-THD) | 2 | |
| 6V9189 | 13 LOCKNUT (M8X1.25-THD) | 4 | |
| 7X0603 | 14 WASHER-HARD (9.9X35X2.5-MM THK) | 4 | |
| 8M4791 | 15 WASHER-HARD (13.5X27X3-MM THK) | 2 | |
| 8T4139 | 16 BOLT (M12X1.75X30-MM) | 2 |
