System And Components
472-2967 KIT-GUARDAN ATTACHMENT
Group No: 472-2967 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3915623 | 1 PLATE | 2 | |
| 4984735 | 2 PLATE AS (RH) | 1 | |
| 4933375 | 3 PLATE AS (LH) | 1 | |
| 4849755 | 4 PLATE | 1 | |
| 4890522 | 5 COVER AS | 1 | |
| 1599540 | NUT-WELD (M8X1.25-THD) | 1 | |
| 3429920 | 6 BOLT-FLANGE HEAD (M8X1.25X20-MM) | 1 | |
| 9X2045 | 7 SCREW-TRUSS HEAD (M6X1X20-MM) | 4 | |
| 5C7261 | 8 NUT (M8X1.25-THD) | 1 | |
| 5P4116 | 9 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 6V7743 | 10 LOCKNUT (M6X1-THD) | 4 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4133 | 12 NUT (M10X1.5-THD) | 3 | |
| 8T4196 | 13 BOLT (M10X1.5X35-MM) | 3 | |
| 8T4205 | 14 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 8T4908 | 15 BOLT (M8X1.25X25-MM) | 1 | |
| 9X2038 | 16 WASHER (7X19X2-MM THK) | 2 |
