Assembly
100%

144-6708 AXLE GP-DRIVE & STEERINGS/N 7FS1-179

Group No: 144-6708
Part NumberPart NameQty
0S15851 BOLT (1/2-13X1.5-IN)30
09807352 BUTTON2
15911523 SHAFT-PINION6
15911514 WASHER6
15911505 PINION-PLANETARY6
15911496 WASHER6
15911487 GEAR2
15952368 WASHER2
15952339 NUT2
159114710 GEAR-RING2
6K493611 BOLT-LOCKING (3/8-16X0.625-IN)8
119712212 LOCK4
159114613 HUB2
006700614 RING2
9K117215 CONE-BEARING4
9K117116 CUP-BEARING4
159114517 HUB2
159114418 SEAL2
159114319 DISC-BRAKE2
6V236020 WASHER-HARD (20X32X3-MM THK)36
159114221 BOLT36
2K482122 LOCKNUT (5/8-18-THD)56
091566823 WASHER56
159114124 SPINDLE2
112816825 SEAL-OIL2
159115426 STUD44
159113827 KNUCKLE (LH)1
159114028 KNUCKLE (RH)1
203025429 SHIM (0.08-MM THK)12
203025530 SHIM (0.13-MM THK)8
203025631 SHIM (0.51-MM THK)4
159113432 SEAL4
081900433 SCREW-BOLT16
081900334 FITTING-GREASE4
239533635 PIN4
081900636 NUT4
086939537 SCREW-STOP4
098106838 CROSS & BEARING AS2
159113139 JOINT AS (LH)1
159115940 SEAL2
159115841 BUSHING2
159115742 BUSHING4
1B517443 PLUG-PIPE1
159115644 AXLE-HOUSING1
5F543445 VALVE AS-VENT1
159113246 JOINT AS (RH)1
159112747 DIFFERENTIAL GP1
159115548 STUD4
091559949 PLUG3
077533050 BUSHING-TERMINAL2
159113051 NUT2
159247152 ROD END (THREAD, LH)1
159247353 TIE ROD AS1
159112954 PIN-COTTER2
159247255 ROD END (THREAD, RH)1
159171556 STUD8
077290057 STUD44
005859358 SEAL-O-RING6
053565559 BUTTON-THRUST6
7X559160 SETSCREW6
053559461 WASHER (13.46X22.35X2.29-MM THK)30
263744662 YOKE-INPUT1
264132863 DEFLECTOR1
4D443164 BEARING-ALIGNING2
1591128BRAKE GP-SERVICE2
1592470KIT-SPIDER (AXLE)2
