System And Components
362-3144 VALVE GP-MAIN CONTROLS/N L8X1-UP
Group No: 362-3144
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1H5728 | 1 SEAL-O-RING | 3 | |
| 1P3704 | 2 SEAL-RECTANGULAR | 1 | |
| 1P3705 | 3 SEAL-RECTANGULAR | 1 | |
| 2J6274 | 4 SEAL-O-RING | 6 | |
| 2S4078 | 5 SEAL-O-RING | 3 | |
| 3H3385 | 6 SEAL-O-RING | 2 | |
| 4B4158 | 7 SCREW-DRIVE (NO 4X0.25-IN) | 6 | |
| 4J0523 | 8 SEAL-O-RING | 4 | |
| 4T1860 | 9 VALVE GP-SHUTTLE (BALL RESOLVER) | 1 | |
| 4T5896 | 10 VALVE GP-CHECK | 1 | |
| 5P8077 | 11 FLANGE-HALF | 6 | |
| 6E1291 | 12 VALVE-CONTROL | 1 | |
| 6V0852 | 13 CAP-DUST | 3 | |
| 7J1592 | 14 COVER | 1 | |
| 7J7852 | 15 SPRING | 1 | |
| 7X2546 | 16 BOLT (M10X1.5X180-MM) | 6 | |
| 7X2549 | 17 BOLT (M12X1.75X100-MM) | 2 | |
| 8L6565 | 18 PIN-SPRING | 6 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4122 | 20 WASHER-HARD (17X32X3.5-MM THK) | 12 | |
| 8T4140 | 21 BOLT (M16X2X60-MM) | 12 | |
| 8T4192 | 22 BOLT (M12X1.75X25-MM) | 2 | |
| 8T5436 | 23 BOLT (M10X1.5X130-MM) | 6 | |
| 9L9188 | 24 SPRING-VALVE | 3 | |
| 0959804 | 25 BOLT-SOCKET HEAD (M12X1.75X110-MM) | 4 | |
| 1024156 | 26 VALVE-CONTROL (LOAD CHECK) | 3 | |
| 1024158 | 27 PLUG AS | 3 | |
| 3G5003 | 27A BUSHING | 1 | |
| 1024157 | PLUG | 1 | |
| 1106349 | 28 FITTING AS (QUICK DISCONNECT) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 1128244 | 29 HOUSING | 1 | |
| 1138263 | 30 PISTON | 3 | |
| 1438912 | 31 VALVE GP-RELIEF (PUMP BACKUP) | 1 | |
| 1471223 | 32 VALVE GP-SOLENOID (24-VOLT)(ON, OFF, FLOAT) | 1 | |
| 1488406 | 33 PLUG AS | 3 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 1552291 | 34 HOUSING | 1 | |
| 1620177 | 35 PLUG AS | 5 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 1645567 | 36 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1655085 | 37 BOLT-SOCKET HEAD (M12X1.75X160-MM) | 6 | |
| 1837263 | 38 PLUG AS | 2 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 2038482 | 39 MANIFOLD | 1 | |
| 2048000 | 40 MOUNTING-CABLE TIE | 4 | |
| 2078218 | 41 PLUG AS | 4 | |
| 7J0204 | SEAL-O-RING | 1 | |
| 9S8007 | PLUG (3/8-24-THD) | 1 | |
| 2176719 | 42 ACTUATOR GP-PILOT CONTROL (HEAD END) | 1 | |
| 2176719 | 42A ACTUATOR GP-PILOT CONTROL (TILT CYLINDER ROD END) | 1 | |
| 2176719 | 42B ACTUATOR GP-PILOT CONTROL (LIFT CYLINDER ROD END) | 1 | |
| 2176720 | 43 ACTUATOR GP-PILOT CONTROL (ROD END) | 1 | |
| 2176720 | 43A ACTUATOR GP-PILOT CONTROL (TILT CYLINDER HEAD END) | 1 | |
| 2176720 | 43B ACTUATOR GP-PILOT CONTROL (LIFT CYLINDER HEAD END) | 1 | |
| 3664694 | 46 PLUG AS | 2 | |
| 7J0204 | SEAL-O-RING | 1 | |
| 3603676 | PLUG | 1 | |
| 3664695 | 47 PLUG AS | 8 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 3664699 | 48 PLUG AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3603692 | PLUG (9/16-18-THD) | 1 | |
| 3676001 | 49 PLUG AS | 1 | |
| 4J7533 | SEAL-O-RING | 1 | |
| 3603675 | PLUG (5/16-24-THD) | 1 | |
| 3676002 | 50 PLUG AS | 15 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 3603677 | PLUG (7/16-20-THD) | 1 | |
| 3700438 | 51 VALVE GP-PRESSURE REDUCING (DEAD ENGINE, LIFT ARM LOWER) | 1 | |
| 3961209 | 53 VALVE GP-SOLENOID (24-VOLT)(HYDRAULIC ACCUMULATOR) | 1 | |
| 4655626 | NUT-SPECIAL (M18X1.5-THD) | 1 | |
| 3962304 | KIT-SEAL | 1 | |
| 3678532 | COIL AS (24-VOLT) | 1 | |
| 4237705 | 54 VALVE GP-RELIEF (LIFT, TILT) | 2 | |
| 4237706 | 55 VALVE GP-RELIEF (TILT CYLINDER ROD END) | 1 | |
| 4237707 | 56 VALVE GP-RELIEF (LIFT CYLINDER ROD END) | 1 | |
| 4237707 | 56A VALVE GP-RELIEF (TILT CYLINDER HEAD END) | 1 | |
| 4237708 | 57 VALVE GP-RELIEF (LIFT CYLINDER HEAD END) | 1 | |
| 9R5008 | 58 SPACER (11X20X6-MM THK) | 8 | |
| 3499267 | VALVE GP-CONTROL | 1 |
