System And Components
397-9390 CYLINDER GP-BULLDOZER LIFT -BULLDOZER LIFTS/N 2T91-UP
Group No: 397-9390
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3G0910 | 1 CAP-BEARING | 1 | |
| 3G0911 | 2 SHIM (0.8-MM THK) | 28 | |
| 9X3592 | 3 SEAL AS | 1 | |
| 9X3590 | RING-SEAL | 1 | |
| 9X3591 | RING-EXPANDER | 1 | |
| 1195445 | 4 RING | 1 | |
| 2330621 | 5 SEAL-WIPER | 1 | |
| 2669985 | 6 HEAD | 1 | |
| 3538621 | 7 PISTON | 1 | |
| 4199163 | 8 CYLINDER AS-HYDRAULIC | 1 | |
| 5J1192 | 8A BUSHING | 2 | |
| 4199171 | 9 ROD AS | 1 | |
| 1672184 | 10 SEAL AS-BUFFER | 1 | |
| 1672318 | 11 SEAL-U-CUP | 1 | |
| 1865147 | 12 RING-WEAR | 1 | |
| 2J0564 | 13 LOCKNUT (2-12-THD) | 1 | |
| 2J3961 | 14 RING-BACKUP | 1 | |
| 2J8163 | 15 SEAL-O-RING | 1 | |
| 3E6703 | 16 SEAL-O-RING | 1 | |
| 7X0851 | 17 NUT (M24X3-THD) | 4 | |
| 8T0672 | 18 BOLT (M24X3X160-MM) | 4 |
