System And Components
389-1475 PUMP GP-PISTON -BRAKE, FANS/N 2T91-UP
Group No: 389-1475
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3648631 | 1 ROTATING GP-PUMP (IMPLEMENT) | 1 | |
| 1749994 | 2 PISTON-CONTROL | 1 | |
| 2595507 | 3 ROD-PISTON | 1 | |
| 2793393 | 4 SWASHPLATE | 1 | |
| 2095984 | 5 SHAFT | 1 | |
| 1985351 | 6 PLUG | 1 | |
| 8T7525 | 7 SEAL-O-RING | 1 | |
| 1949472 | 8 SPRING | 1 | |
| 1917582 | 9 SHIM (2.5-MM THK) | 1 | |
| 1949473 | 10 RING | 1 | |
| 3642043 | 11 BEARING-ROLLER | 1 | |
| 1917583 | 12 BEARING-TAPERED | 1 | |
| 1949474 | 13 BEARING-CRADLE | 2 | |
| 1559127 | 14 SEAL | 1 | |
| 2314707 | 15 SEAL-O-RING | 1 | |
| 1683504 | 16 SEAL | 1 | |
| 8T9597 | 17 RING-RETAINING | 1 | |
| 9X6032 | 18 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 4 | |
| 9S8005 | 19 PLUG (3/4-16-THD) | 1 | |
| 3K0360 | 20 SEAL-O-RING | 1 | |
| 1204394 | 21 PLUG-BREAK OFF | 1 | |
| 9X8979 | 22 DOWEL | 1 | |
| 3251480 | 23 COUPLING-SPLINE | 1 | |
| 2275904 | 24 SEAL-O-RING | 1 | |
| 1559137 | 25 PLATE | 1 | |
| 3680800 | 26 VALVE GP-PUMP CONTROL (IMPLEMENT) | 1 | |
| 2807870 | 27 GASKET | 1 | |
| 8T8442 | 28 BOLT-SOCKET HEAD (M6X1X30-MM) | 4 |
