System And Components
415-8382 LINES GP-FUELS/N DTG1-UP
Group No: 415-8382
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6W7293 | 1 GROMMET | 1 | |
| 7Y8165 | 2 GROMMET | 2 | |
| 7Y8167 | 3 GROMMET (50-MM ID) | 1 | |
| 8C8431 | 4 TEE | 1 | |
| 8T9655 | 5 MOUNT-ISOLATION | 6 | |
| 0932065 | 6 GROMMET | 3 | |
| 1652881 | 7 VALVE-BALL (SEDIMENT, WATER) | 1 | |
| 1849114 | 8 ELBOW | 1 | |
| 1911782 | 9 SPACER (8.5X12.7X38.2-MM THK) | 1 | |
| 1911783 | 10 SPACER (8.5X12.7X87.3-MM THK) | 2 | |
| 2609244 | 11 ELBOW | 1 | |
| 3056873 | 12 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 3218657 | 13 ELBOW AS | 1 | |
| 6V8076 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3535142 | 14 ADAPTER AS | 1 | |
| 2198136 | ADAPTER | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3686658 | 15 VALVE | 1 | |
| 3794369 | 16 ADAPTER | 2 | |
| 3794370 | 17 ADAPTER-ELBOW | 2 | |
| 3855773 | 18 CONNECTOR AS | 1 | |
| 5P1046 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3906840 | 19 PUMP GP-FUEL PRM & PRIM FILTER | 1 | |
| 4182839 | 20 HOSE AS | 1 | |
| 2643518 | CONNECTOR-RECEPTACLE | 1 | |
| 4182840 | 21 HOSE AS | 1 | |
| 4182843 | 22 HOSE AS | 1 | |
| 3550633 | COUPLER-QUICK DISCONNECT | 1 | |
| 3478645 | 23 HOSE (180-CM) | ||
| 3478645 | 23A HOSE (21-CM) | ||
| 4182845 | 24 HOSE | 1 | |
| 4182848 | 25 HOSE | 1 | |
| 4211935 | 26 PLATE AS | 1 | |
| 4236434 | 27 SENSOR GP-LIQUID LEVEL (WATER IN FUEL) | 1 | |
| 4244755 | 28 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 9R2821 | BOSS (M10X1.5X15-MM) | 1 | |
| 0875841 | PLATE | 1 | |
| 4255634 | 29 CONNECTOR | 1 | |
| 4649516 | 30 HOSE | 1 | |
| 4649529 | 31 HOSE AS | 1 | |
| 4760511 | 32 PLATE AS | 1 | |
| 5017449 | 33 ADAPTER AS | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 5042756 | ADAPTER | 1 | |
| 1699763 | 34 CONNECTOR | 1 | |
| 2041611 | 35 STRAP-CABLE (DUAL) | 1 | |
| 1772215 | 36 STRAP-DUAL CLAMP | 2 | |
| 2147568 | 37 SEAL-O-RING | 6 | |
| 2287089 | 38 SEAL-O-RING | 1 | |
| 2339821 | 39 VALVE AS-CHECK | 1 | |
| 0336042 | SEAL-O-RING | 1 | |
| 2385081 | 40 SEAL-O-RING | 4 | |
| 3133492 | 41 PLUG AS | 1 | |
| 9S4190 | PLUG-O-RING (7/8-14-THD) | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3196245 | 42 ADAPTER AS | 1 | |
| 8T6663 | ADAPTER-PORT | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3295459 | 43 ADAPTER AS | 1 | |
| 5P1404 | ADAPTER | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3432387 | 44 CLIP (LOOP) | 10 | |
| 3445360 | 45 CLIP (LOOP) | 3 | |
| 3514318 | 46 CLIP (LOOP) | 20 | |
| 3514319 | 47 CLIP (LOOP) | 4 | |
| 3535112 | 48 ADAPTER AS | 1 | |
| 9X0262 | ADAPTER | 1 | |
| 2147566 | SEAL-O-RING | 2 | |
| 5G3676 | 49 GROMMET | 2 | |
| 5P4924 | 50 ELBOW | 1 | |
| 5P8939 | 51 GROMMET | 1 | |
| 5V9155 | 52 CLAMP-HOSE | 5 | |
| 6S8620 | 53 CLAMP-HOSE | 6 | |
| 7V6571 | 54 GROMMET | 3 | |
| 7X0579 | 55 WASHER-HARD (8.8X25.5X2-MM THK) | 6 | |
| 7X2539 | 56 BOLT (M8X1.25X110-MM) | 2 | |
| 8T1889 | 57 CLIP (SLOT) | 6 | |
| 8T1890 | 58 CLIP (TAB) | 6 | |
| 8T4121 | 59 WASHER-HARD (11X21X2.5-MM THK) | 49 | |
| 8T4136 | 60 BOLT (M10X1.5X25-MM) | 10 | |
| 8T4137 | 61 BOLT (M10X1.5X20-MM) | 33 | |
| 8T4191 | 62 BOLT (M10X1.5X16-MM) | 2 | |
| 8T4195 | 63 BOLT (M10X1.5X30-MM) | 3 | |
| 8T4198 | 64 BOLT (M10X1.5X100-MM) | 1 | |
| 8T6869 | 65 BOLT (M8X1.25X60-MM) | 1 | |
| 8C6959 | 67 HOSE (25-CM) |
