421-9597 DRIVE GP-ACCESSORYS/N N9Z1-UP

Group No: 421-9597
Part NumberPart NameQty
19036351 PULLEY (8-GROOVE)1
27218892 ALTERNATOR GP-CHARGING (24-VOLT, 150-AMPERE)1
47205593 COMPRESSOR GP-REFRIGERANT1
34299644 SPACER (6.8X20X50.8-MM THK)2
34299695 INSERT4
37196766 BRACKET AS1
42195097 GUARD1
42195478 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)1
8T3612NUT-WELD (M8X1.25-THD)1
42195489 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)1
191630110 STUD-TAPERLOCK (M8X1.25X40-MM)2
198477611 WASHER-HARD (8.8X20X8-MM THK)4
255128112 BOLT-FLANGE HEAD (M8X1.25X100-MM)4
305538513 BOLT (M8X1.25X50-MM)4
374848014 BELT-SERPENTINE1
8T412115 WASHER-HARD (11X21X2.5-MM THK)4
8T668516 BOLT (M10X1.5X110-MM)4
