System And Components
115-4472 PUSH ARM GPS/N 8RJ1-UP; 2SP1-UP
Group No: 115-4472
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4F0255 | 1 PIN | 2 | |
| 4T1520 | 2 CAGE AS | 1 | |
| 6J5383 | 2A BEARING | 1 | |
| 8E5701 | 3 SHIM (0.8-MM THK) | 52 | |
| 8E5703 | 4 SHIM (0.8-MM THK) | 78 | |
| 8J2880 | 5 CAP AS-BEARING | 3 | |
| 1153523 | 6 CYLINDER GP-TILT | 1 | |
| 1154473 | 7 ARM AS (RH) | 1 | |
| 3G6313 | 7A BEARING | 1 | |
| 1U2533 | 7B BAR | 1 | |
| 4T0732 | 7C BRACKET | 1 | |
| 1796153 | 7D BEARING | 1 | |
| 8P9770 | 7E PLATE | 1 | |
| 1154474 | 8 ARM AS (LH) | 1 | |
| 3G6313 | 8A BEARING | 1 | |
| 1U2533 | 8B BAR | 1 | |
| 4T0780 | 8C TRUNNION | 1 | |
| 1796153 | 8D BEARING | 1 | |
| 8P9770 | 8E PLATE | 1 | |
| 1154522 | 8F BRACKET | 1 | |
| 1249672 | 9 BRACE AS-TILT | 1 | |
| 8E2887 | 9A YOKE | 1 | |
| 1606306 | 10 CAP-BEARING | 2 | |
| 3B4626 | 11 PIN-COTTER | 2 | |
| 3F6185 | 12 PIN | 2 | |
| 6V9167 | 13 BOLT (M20X2.5X140-MM) | 8 | |
| 7X2566 | 14 BOLT (M20X2.5X110-MM) | 6 | |
| 8C8478 | 15 BOLT (M20X2.5X140-MM) | 4 | |
| 8T4123 | 16 WASHER (22X35X3.5-MM THK) | 6 | |
| 8T4131 | 17 NUT (M20X2.5-THD) | 22 | |
| 8T5439 | 18 WASHER-HARD (21.5X45X6-MM THK) | 6 | |
| 8T6381 | 19 BOLT (M20X2.5X120-MM) | 4 |
