System And Components
135-1837 BELT TENSIONER GPS/N 8DN1-849
Group No: 135-1837
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1086195 | 1 ROD AS | 2 | |
| 1335666 | 2 GASKET | 2 | |
| 1087928 | 3 SUPPORT AS | 2 | |
| 7S9847 | 4 WASHER-CONICAL | 4 | |
| 7K9202 | 5 SEAL-LIP TYPE | 2 | |
| 1086592 | 6 BAR | 2 | |
| 8B6349 | 7 DOWEL | 4 | |
| 1086591 | 8 PLUNGER | 2 | |
| 1086590 | 9 PIN | 2 | |
| 1086589 | 10 PLATE | 2 | |
| 7P7736 | 11 BUSHING | 2 | |
| 1086588 | 12 PLATE | 2 | |
| 9X8257 | 13 WASHER (17.5X30X3.5-MM THK) | 16 | |
| 8T4193 | 14 BOLT (M16X2X50-MM) | 8 | |
| 6V0852 | 15 CAP-DUST | 2 | |
| 6V6757 | 16 ELBOW-PIPE | 2 | |
| 6V3966 | 17 FITTING AS | 2 | |
| 5M6708 | 18 WASHER (0.609X1.25X0.219-IN THK) | 4 | |
| 8T1447 | 19 BOLT-SOCKET HEAD (M16X2X70-MM) | 8 | |
| 1086191 | 20 GUARD AS | 2 | |
| 8T4200 | 21 BOLT (M8X1.25X16-MM) | 2 | |
| 5P4116 | 22 WASHER-HARD (8.8X20.5X2-MM THK) | 6 | |
| 3J1907 | 23 SEAL-O-RING | 4 | |
| 8T4779 | 24 BOLT (M16X2X35-MM) | 8 | |
| 8T4190 | 25 BOLT (M16X2X25-MM) | 2 | |
| 8T4132 | 26 NUT (M16X2-THD) | 2 | |
| 7X7729 | 27 WASHER (11X25X3-MM THK) | 4 | |
| 8T4136 | 28 BOLT (M10X1.5X25-MM) | 4 | |
| 1515200 | 29 PLATE | 4 | |
| 1086594 | 30 BLOCK | 2 | |
| 1087102 | 31 SPACER | 4 | |
| 4D4431 | 32 BEARING-ALIGNING | 2 | |
| 1329767 | 33 PIN AS | 2 | |
| 8T4956 | 34 BOLT (M12X1.75X35-MM) | 2 | |
| 7X0618 | 35 WASHER-HARD (13.5X40X5-MM THK) | 2 | |
| 1L1486 | 36 SPACER (0.5X0.875X0.5-IN THK) | 2 | |
| 1087841 | 37 SEAL AS-ROD | 2 | |
| 1087839 | 38 SEAL-U-CUP | 2 | |
| 1086213 | 39 SEAL-LIP TYPE | 2 | |
| 8T4223 | 40 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 7X2550 | 41 BOLT (M12X1.75X110-MM) | 8 | |
| 1085985 | 42 VALVE | 2 | |
| 3K0360 | 43 SEAL-O-RING | 2 | |
| 8T7547 | 44 BOLT (M8X1.25X30-MM) | 4 | |
| 1082571 | 45 GUIDE | 2 | |
| 8T5668 | 46 RING-WEAR | 4 | |
| 1086194 | 47 SPACER (24.5X73X16-MM THK) | 2 | |
| 8T5379 | 48 BOLT (M24X3X50-MM) | 2 | |
| 1082570 | 49 CYLINDER | 2 | |
| 7B8451 | 50 SHIM (0.01-MM THK) | 8 | |
| 1247272 | 51 SWITCH AS-BALL | 2 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1028812 | SEAL | 1 | |
| 6V1657 | 52 SEAL-RECTANGULAR | 2 | |
| 1P3704 | 53 SEAL-RECTANGULAR | 2 | |
| 1199718 | 54 MANIFOLD | 1 | |
| 1199708 | 55 VALVE-NEEDLE | 4 | |
| 5P6442 | 56 HOSE | ||
| 1343685 | 57 ACCUMULATOR AS | 2 | |
| 1333093 | 58 STRAP AS | 2 | |
| 1327113 | 59 PLUG | 2 | |
| 7M8485 | 60 SEAL-O-RING | 4 | |
| 1199711 | 61 MANIFOLD | 1 | |
| 1199738 | 62 SHIM (0.13-MM THK) | 2 | |
| 1P4278 | 63 CLAMP-HOSE | 2 | |
| 6Y4638 | 64 PLUG-HEX SOCKET (1-5/16-12-THD) | 2 | |
| 1214588 | 65 FILM-WARNING (HIGH PRESSURE CYLINDER) | 2 | |
| 2K4973 | 66 LOCKNUT (3/8-16-THD) | 4 |
