System And Components
522-9113 CONTROL GP-TRANSMISSION HYDS/N NNA1546-UP; JJP1-UP
Group No: 522-9113
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4F4097 | 1 SEAL-O-RING | 1 | |
| 6D7889 | 2 SEAL-O-RING | 6 | |
| 1481928 | 3 VALVE-RELIEF | 1 | |
| 9X4609 | 4 SEAL-O-RING | 1 | |
| 2234434 | 5 VALVE GP-RELIEF (TRANSMISSION HYDRAULIC CONTROL) | 1 | |
| 2345013 | 6 SENSOR GP-TEMPERATURE (TRANSMISSION OIL) | 1 | |
| 2443114 | 7 VALVE GP-MODULATING (24-VOLT)(TRANSMISSION HYDRAULIC CONTROL) | 6 | |
| 3723328 | 8 SLEEVE | 6 | |
| 3159859 | 9 PLUG AS | 1 | |
| 9S8008 | PLUG (1-1/16-12-THD) | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3551259 | 10 TUBE AS | 1 | |
| 4523974 | 11 HARNESS AS-TRANSMISSION | 1 | |
| 3629228 | 12 TUBE AS | 1 | |
| 4400172 | 13 PLATE-ORIFICE | 6 | |
| 3696868 | 14 CONNECTOR AS | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3696867 | ADAPTER | 1 | |
| 3953194 | 15 TUBE AS | 1 | |
| 1305300 | 16 CLIP | 3 | |
| 1325789 | 17 CLIP (LADDER) | 5 | |
| 1646867 | 18 CONNECTOR AS | 1 | |
| 2R6806 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1646877 | 19 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 0307947 | ADAPTER-ELBOW | 1 | |
| 1M3466 | 20 CLIP | 1 | |
| 2042281 | 21 STRAP-CABLE | 1 | |
| 2048000 | 22 MOUNTING-CABLE TIE | 1 | |
| 2697852 | 23 SEAL-O-RING | 6 | |
| 3196220 | 24 ELBOW AS | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3523968 | 25 CLIP (LADDER) | 1 | |
| 3196219 | 26 ELBOW AS | 1 | |
| 6V9005 | ELBOW | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3930721 | 27 GASKET | 6 | |
| 6K9194 | 28 ELBOW | 1 | |
| 6V0852 | 29 CAP-DUST | 6 | |
| 6V4248 | 30 BOLT (M10X1.5X25-MM) | 1 | |
| 6V5220 | 31 BOLT (M8X1.25X65-MM) | 12 | |
| 6V5839 | 32 WASHER (11X21X2.5-MM THK) | 9 | |
| 6V6317 | 33 BOLT (M10X1.5X20-MM) | 7 | |
| 7K1181 | 34 STRAP-CABLE | 7 | |
| 7S0530 | 35 CLIP | 1 | |
| 8L2777 | 36 SEAL-O-RING | 6 | |
| 8S8820 | 37 CLIP | 2 | |
| 9M1974 | 38 WASHER-HARD (8.8X16X2-MM THK) | 16 | |
| 8T0100 | 39 BOLT (M8X1.25X60-MM) | 4 |
