333-4938 WIRING GP-CABS/N H9K345-UP

Group No: 333-4938

Part Number	Part Name	Qty
2483289	1 CIRCUIT BREAKER AS (20-AMPERE)(AUTOMATIC RESET)	1
3E5275	2 SWITCH AS-ROTARY (WIPER, WASHER)	1
2H3920	LOCKWASHER	1
1552265	KIT-CONNECTING PLUG (8-PIN)	1
6V8369	NUT (7/16-28-THD)	1
7T9302	KNOB AS-WIPER SWITCH (WASHER)	1
0140816	SETSCREW (8-32X0.5-IN)	1
8T8730	SOCKET-CONNECTOR (16-GA TO 20-GA)	8
3E6328	3 ALARM GP (24-VOLT)(ACTION)	1
6I1418	4 SPACER (8.2X12.7X28.7-MM THK)	8
8T7524	5 SEAL-O-RING	2
8T9655	6 MOUNT-ISOLATION	16
8Y6335	7 LAMP-INTERIOR (24-VOLT)(MAP LIGHT)	1
1058034	8 SWITCH AS-LIMIT (DOOR)	1
1138373	9 SCREW-BUTTON HEAD (10-32X0.75-IN)	3
1138490	10 FUSE (10-AMPERE)	27
1138491	11 FUSE (15-AMPERE)	14
1138492	12 FUSE (20-AMPERE)	3
1172311	13 SOCKET-AUXILIARY POWER (12-VOLT)	1
1239694	14 HORN	1
1631876	15 LAMP-LED (24-VOLT, RED)	1
1688772	16 SPEAKER AS-RADIO	2
1809900	17 CAP AS	2
5P7958	SLEEVE-CABLE SPLICE	1
8C6354	CAP-RECEPTACLE (ET CONNECTOR)	1
1799392	LANYARD	1
1878675	18 GASKET	1
2253322	20 SCREW-TRUSS HEAD (M6X1X10-MM)	4
2309174	21 CIRCUIT BREAKER AS (15-AMPERE)	2
6V8378	NUT (10-32-THD)	2
8F1434	LOCKWASHER	2
8T0328	WASHER-HARD (5.5X10X1-MM THK)	2
2337424	22 BAR-BUS	1
2418368	23 SWITCH GP-MAGNETIC (24-VOLT)(MAIN RELAY)	2
2421555	24 PULLER-FUSE	1
2482841	25 RELAY AS (24-VOLT)	11
2514339	26 SWITCH AS-ROCKER (24-VOLT)(REAR FLOODLIGHTS)	1
2552752	27 SWITCH GP-START (IGNITION)(KEY)	1
2566454	28 SENSOR-TEMPERATURE (2-PIN)(AIR CONDITIONER)	2
2657981	29 SWITCH AS-ROCKER (24-VOLT)(AIR CONDITIONER CONTROL)	1
2727239	30 BLOCK AS	1
2757741	31 SWITCH GP-WIPER (24-VOLT)(FRONT)	1
2757741	31A SWITCH GP-WIPER (24-VOLT)(REAR)	1
2802709	32 CIRCUIT BREAKER AS (15-AMPERE, MANUAL RESET)	2
2848905	33 CONTROL GP-UNPRGMED MONITOR (ADVISOR)	1
2888557	34 CONTROL AS-A/C & HEATER (BLOWER FAN SPEED)	1
3070649	35 KNOB	3
3217071	36 PLATE	2
3223621	37 CONTROL GP-UNPROGRAMMED (IMPLEMENT, POWER TRAIN)	2
3327144	38 GASKET	1
3327146	39 PLATE AS	1
3327147	40 PLATE	1
3327148	41 PLATE AS	1
3327150	42 PLATE	1
3334939	43 HARNESS AS-CAB (AUXILIARY CIRCUIT)	1
3341108	44 PANEL AS	1
2717312	KNOB (BLOWER, TEMPERATURE)	2
3341598	45 WIRE AS	1
3355366	46 SOCKET-AUXILIARY POWER (12-VOLT)	1
3378982	47 CABLE AS	1
1598047	CABLE-ELECTRICAL (0-GA, RED)(107-CM)
3253767	SLEEVE (76-CM)
9G4344	TERMINAL-RING (4-GA, 1/2-IN SCREW)	2
2848481	TERMINAL AS-RING	1
1193662	TUBE-HEAT SHRINK (10.85-MM DIA)(4-CM)
2891502	TERMINAL AS-RING	1
1257876	TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM)
1M4986	TERMINAL-RING (0-GA, 1/2-IN SCREW)	1
6V2369	CABLE (4-GA, BLACK)(2.4-M)
3378983	48 CABLE AS	1
6V2369	CABLE (4-GA, BLACK)(0.4-M)
2848481	TERMINAL AS-RING	1
1193662	TUBE-HEAT SHRINK (10.85-MM DIA)(4-CM)
2891502	TERMINAL AS-RING	1
1257876	TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM)
3378984	49 CABLE AS	1
2767500	TERMINAL AS-RING	1
1257876	TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM)
2848481	TERMINAL AS-RING	1
1193662	TUBE-HEAT SHRINK (10.85-MM DIA)(4-CM)
3396508	50 PLATE	1
3407161	51 CONVERTER-POWER (24-VOLT TO 12-VOLT)	1
3521145	53 DIODE	5
3634995	54 RESISTOR	1
3634996	55 RESISTOR	1
3751478	56 LAMP GP-DOME (24-VOLT)	1
5006151	57 HARNESS AS-CAB (REAR)	1
3856800	58 CLAMP AS	1
1243019	61 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
1305300	62 CLIP	12
1325789	63 CLIP (LADDER)	6
5T6374	64 SPACER (11X20X40-MM THK)	1
1934622	65 SCREW-BUTTON HEAD (10-32-THD)	4
1997854	66 SPACER (11.8X20X45-MM THK)	1
2042281	67 STRAP-CABLE	7
2048000	68 MOUNTING-CABLE TIE	3
2430774	70 SWITCH AS-ROCKER (24-VOLT)(STAIRWAY ACCESS LIGHTS)	1
2511195	71 SWITCH AS-ROCKER (24-VOLT)(FRONT FLOODLIGHTS)	1
2512031	72 SWITCH AS-ROCKER (24-VOLT)(RUNNING LIGHTS)	1
2532101	73 SWITCH AS-ROCKER (24-VOLT)(DOME LIGHT)	1
3055629	74 LAMP (24-VOLT)	1
3651252	75 FILM-IDENTIFICATION (FUSE PANEL)	1
3651253	76 FILM-IDENTIFICATION (FUSE PANEL)	1
3996711	77 HARNESS AS-CAB (MAIN)	1
3S2093	78 STRAP-CABLE	68
4P7581	79 CLIP (LADDER)	1
5C2890	80 NUT (M6X1-THD)	4
5C7261	81 NUT (M8X1.25-THD)	4
5C9553	82 BOLT (M6X1X16-MM)	39
5P4116	83 WASHER-HARD (8.8X20.5X2-MM THK)	5
6P6641	85 GROMMET	1
6V3822	86 BOLT (M10X1.5X35-MM)	2
6V4248	87 BOLT (M10X1.5X25-MM)	3
6V5221	88 BOLT (M8X1.25X80-MM)	4
8T4191	89 BOLT (M10X1.5X16-MM)	2
6V8214	90 BOLT (M6X1X20-MM)	4
6V8227	91 NUT (M18X1.5-THD)	1
7K1181	92 STRAP-CABLE	47
7U4892	93 SCREW (8-32X0.75-IN)	6
7X0579	94 WASHER-HARD (8.8X25.5X2-MM THK)	12
7X7729	95 WASHER (11X25X3-MM THK)	18
7Y3173	96 SCREW-BUTTON HEAD (M4X0.7X12-MM)	8
7Y7388	97 SCREW-BUTTON HEAD (M5X0.8X12-MM)	4
7Y7389	98 SCREW (M5X0.8X16-MM)	4
8T0289	100 BOLT (M5X0.8X20-MM)	2
8T4137	101 BOLT (M10X1.5X20-MM)	6
8T4192	102 BOLT (M12X1.75X25-MM)	4
8T4189	103 BOLT (M8X1.25X20-MM)	1
8T4205	104 WASHER-HARD (7.2X14.5X2-MM THK)	2
8T4223	105 WASHER-HARD (13.5X25.5X3-MM THK)	4
8T5005	106 BOLT (M10X1.5X70-MM)	2
8T9310	107 SCREW (M3X0.5X20-MM)	4
9X2045	108 SCREW-TRUSS HEAD (M6X1X20-MM)	6
9X8256	109 WASHER (6.6X12X2-MM THK)	51
7X7877	110 STRIP-EDGE (20-CM EACH)
7X7877	110A STRIP-EDGE (18-CM)
7X7877	110B STRIP-EDGE (15.5-CM)
7X7877	110C STRIP-EDGE (6-CM)
2574907	111 COVER AS-ACCESS	3
8T4121	112 WASHER-HARD (11X21X2.5-MM THK)	4
9X2040	113 SCREW-TRUSS HEAD (M10X1.5X25-MM)	2
3445594	114 HARNESS AS-RADIO (AUXILIARY)	1
3445673	115 NUT (M6X1-THD)	1
9X2038	116 WASHER (7X19X2-MM THK)	2
8T4138	117 BOLT (M6X1X20-MM)	1
4P7428	118 CLIP (LADDER)	1
8T4136	119 BOLT (M10X1.5X25-MM)	2
